NEC Display (46") Ultra-Narrow 3x3 TileMatrix Video Wall Solution - Digital Pull-Out X463UN-TMX9P

NEC's complete 46" 3x3 LCD TileMatrix™ Video Wall Solution delivers an all-in-one, easy-to-configure and cost-effective solution that is ideal for dynamic digital signage and command & control applications. Exclusive TileMatrix and TileComp™ technologies combine with the ultra-narrow bezel of the NEC X463UN and the full adjustment capabilities of a Peerless-AV pull-out mount to allow for simple installation and easy access while servicing the video wall. The minimal bezel widths help to avoid interruption of the displayed content while included DVI and RS232 cables can be used to source digital signage content while controlling the display. An NEC Display Wall Calibrator kit is included, allowing for accurate brightness intensity, white point matching and greater color uniformity from screen-to-screen.

Product Type	LCD Monitor
Brand Name	NEC Display
Manufacturer	NEC Display Solutions
Product Model	X463UN-TMX9P
Product Name	(46") Ultra-Narrow 3x3 TileMatrix Video Wall Solution - Digital Pull-Out
Manufacturer Part Number	X463UN-TMX9P
Manufacturer Website Address	http://www.necdisplay.com
Number of Screens	9
Horizontal Viewing Angle	178
Vertical Viewing Angle	178
Backlight Technology	Direct LED
Display Orientation	Landscape/Portrait
Screen Mode	Full HD
Features	Screen SaverSecurity LockTileCompTileMatrix SupportCarbon Footprint MeterAmbient Light SensorVideo WallPicture on PictureSide-by-side View Support
Screen Size	46"
Aspect Ratio	16:9
Response Time	8 ms
Standard Refresh Rate	60 Hz
Brightness	700 Nit
Color Supported	16.7 Million Colors
Maximum Resolution	1920 x 1080
Contrast Ratio	3,500:1
HDMI	Yes
DVI	Yes
VGA	Yes
S-Video	Yes
Composite Video	Yes
Network (RJ-45)	Yes
DisplayPort	Yes
VESA Mount Compatible	Yes
VESA Mount Standard	300 x 300
Height with Stand	29"
Width with Stand	40.30"
Depth with Stand	13"
Height	22.8"
Width	40.3"
Depth	4.6"
Weight (Approximate)	53.57 lb
Operating Power Consumption	120 W
Standby Power Consumption	500 mW
Platform Supported	PCMac
Package Contents	(46") Ultra-Narrow 3x3 TileMatrix Video Wall Solution - Digital Pull-Out 6 x Custom Spacers 9 x DVI Loop-through Cables DVI Cable 9 x Peerless Mounts 8 x Null Modem Cables 3 x Tripp Lite Surge Suppressors Display Wall Calibrator Kit 3 x Overframe Bezel Kits IR Remote Kit Power Cord Batteries CD-ROM (User Manual)
Limited Warranty	3 Year
