Advantech 5-port Ind. Unmanaged GbE Switch EKI-2725-CE EKI-2725

Advantech 5-port Ind. Unmanaged GbE Switch EKI-2725-CE EKI-2725
Price $184.68
Manufacturer: Advantech
Mfg Number: EKI-2725-CE
Model: EKI-2725
Condition: New
The EKI-2725 supports Gigabit Ethernet. The power is a +12 ~ 48 V DC redundant input design, and is secured with a double protection mechanism: Power Polarity Reverse Protect and an Overload Current Fuse. The former tolerates reverse power wiring while the later secures the system from overload currents. Each port of EKI-2725 has 2 LED's to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators. Engineers can simply verify the hardware status by checking the LED, and have troubleshooting easy and quick. EKI-2725 comes with compact metal housing that rates IP30 to help against from dusty industrial environments.
Modular No
Uplink Port No
Stack Port No
Total Number of Network Ports 5
Port/Expansion Slot Details 5 x Gigabit Ethernet Network
Product Type Ethernet Switch
Manufacturer Part Number EKI-2725-CE
Manufacturer Website Address http://www.advantech.com
Manufacturer Advantech Co., Ltd
Product Model EKI-2725
Product Name 5-port Ind. Unmanaged GbE Switch
Product Series EKI-2000
Brand Name Advantech
Network Technology 10/100/1000Base-T
Ethernet Technology Gigabit Ethernet
Media Type Supported Twisted Pair
Layer Supported 2
Form Factor DIN Rail Mountable Wall Mountable
Height 5.5"
Width 1.2"
Depth 3.7"
Manageable No
