Allied Telesis Industrial PoE+ Ethernet Layer 3 Switch AT-IE340-12GP-80 IE340-12GP

The Allied Telesis IE340-12GP managed switch features 8 x 10/100/1000T PoE+ copper ports and 4 x 100/1000X SFP uplinks. A comprehensive feature-set, and built in security, make it ideal for high-density Industrial Environments. 24Gbps switch fabric and 17.8Mpps forwarding packet rate 16K MAC addresses 4K VLANs 9KB jumbo frame size 8 QoS priority queues 511 (Layer 2), 256 (Layer 3) Multicast groups IEEE 802.3at PoE+ sourcing (30W) 240W PoE power budget Alarm input and output ports -40°C to 75°C

Modular	Yes
Total Number of Network Ports	8
Port/Expansion Slot Details	8 x Gigabit Ethernet PoE+ 4 x Gigabit Ethernet Expansion Slot
Product Type	Layer 3 Switch
Manufacturer Part Number	AT-IE340-12GP-80
Manufacturer Website Address	http://www.alliedtelesis.com
Manufacturer	Allied Telesis, Inc
Product Model	IE340-12GP
Product Name	Industrial PoE+ Ethernet Layer 3 Switch
Product Series	IE340
Brand Name	Allied Telesis
Expansion Slot Type	SFP (mini-GBIC)
Number of Total Expansion Slots	4
Number of SFP Slots	4
Network Technology	10/100/1000Base-T 1000Base-X
Ethernet Technology	Gigabit Ethernet
Media Type Supported	Twisted Pair Optical Fiber
Package Contents	Industrial PoE+ Ethernet Layer 3 Switch DIN Rail and Wall Mount Kits
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE REACH China RoHS
Layer Supported	3
Form Factor	DIN Rail Mountable Wall Mountable
Height	6"
Width	3.6"
Depth	5.5"
Power Source	Power Supply PoE+
Power Consumption	271 W
PoE (RJ-45) Port	Yes
PoE Budget	240 W
Manageable	Yes
