Allied Telesis Stackable Intelligent PoE+ Layer 3 Switch AT-X530L-52GPX-10 x530L-52GPX

The x530L-52GPX stackable Gigabit Layer 3 switch is high-performing and feature-rich, with 48 x 100M/1G PoE+ ports, and 4 x 10G uplinks. KEY FEATURES AlliedWare Plus™ Enterprise-class operating system VCStack up to 4 units locally or over distance to support resilient networking Ethernet Protection Switched Ring (EPSRing™) and G.8032 ERPS supports high-speed resilient ring-based networks Power over Ethernet Plus (PoE+) supplies up to 30 Watts to connect and power endpoints such as PTZ security cameras, POS terminals, and wireless access points. Continuous PoE ensures endpoint uptime, even during a switch firmware upgrade Dual fixed power supplies provide a PoE+ power budget of 740 Watts

Modular	Yes
Stack Port	Yes
Total Number of Network Ports	48
Port/Expansion Slot Details	48 x Gigabit Ethernet PoE+ 4 x 10 Gigabit Ethernet Expansion Slot 2 x Stack
Product Type	Layer 3 Switch
Manufacturer Part Number	AT-X530L-52GPX-10
Manufacturer Website Address	http://www.alliedtelesis.com
Manufacturer	Allied Telesis, Inc
Product Model	x530L-52GPX
Product Name	Stackable Intelligent PoE+ Layer 3 Switch
Brand Name	Allied Telesis
Expansion Slot Type	SFP+
Number of Total Expansion Slots	4
Number of SFP+ Slots	4
Network Technology	10GBase-X 10/100/1000Base-T
Ethernet Technology	10 Gigabit Ethernet Gigabit Ethernet
Media Type Supported	Optical Fiber Twisted Pair
Package Contents	Stackable Intelligent PoE+ Layer 3 Switch 19 Inch Rack-Mount Brackets US Power Cord
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	REACH RoHS WEEE EU RoHS China RoHS
Layer Supported	3
Weight (Approximate)	14.77 lb
Form Factor	Rack-mountable
Height	1.7"
Width	17.4"
Depth	16.6"
Power Source	Power Supply
Redundant Power Supply Supported	Yes
Manageable	Yes
