Allied Telesis 12-Port 100/1000/10G Base-T (RJ-45) Stackable Switch with 4 SFP/SFP+Slot AT-XS916MXT

The AT-XS916MXT and AT-XS916MXS switches offer cost effective, high-speed 10G connectivity for servers and storage, and support 100/1000 connections for existing networks. The XS900MX Series enable a highly flexible and reliable network, which can easily scale to meet increasing traffic demands. OverviewThe XS900MX Series are the ideal 10G access switches for enterprise networks or anywhere a relay switch with 10G uplink is required. Theswitches also make the ideal core or aggregation switch, to connect servers and storage in a small network. The AT-XS916MXT features 12 x 100/1000/10GBASE-T and 4 x SFP+ slots. The AT-XS916MXS features 4 x 100/1000/10GBASE-T and 12 x SFP+ slots. Easy managementThe XS900MX Series switches feature Allied Telesis Management FrameworkTM (AMF), a sophisticated suite of management tools that provides a simplified approach to network management. Common tasks are automated or made so simple that the everyday running of a network can be achieved without the need for highly trained, and expensive, network engineers.Powerful features like centralized management, auto-backup, auto-upgrade, auto- provisioning and auto-recovery enable plug-and-play networking and zero-touch management. ResiliencyEthernet Protection Switching Ring (EPSRingTM) and 10 Gigabit Ethernet allow several XS900MX Series switches to form a protected ring capable of recovery within as little as 50ms. This feature is perfect for high performance and high availability in enterprise networks.StackableCreate a VCStack of two XS900MX Series switches (using 10G SFP+ direct attach cables). VCStack provides a highly available system where network resources are spread out across stacked units, reducing the impact if one of the units fails. With VCStack and the XS900MX Series, up to 28 x 10G ports can be provisioned as a single virtual switch in one rack unit.

Product Type	Layer 3 Switch
Product Series	XS900MX
Brand Name	Allied Telesis
Manufacturer	Allied Telesis, Inc
Product Model	AT-XS916MXT
Product Name	12-Port 100/1000/10G Base-T (RJ-45) Stackable Switch with 4 SFP/SFP+Slot
Product Line	CentreCOM
Manufacturer Part Number	AT-XS916MXT-10
Manufacturer Website Address	http://www.alliedtelesis.com
Manageable	Yes
Environmentally Friendly	Yes
Environmental Certification	REACHECORoHSWEEETÜV
Package Contents	12-Port 100/1000/10G Base-T (RJ-45) Stackable Switch with 4 SFP/SFP+Slot US Power Cord
Compatible Rack Unit	1U
Height	1.7"
Width	12.7"
Depth	8.3"
Form Factor	Rack-mountable
Weight (Approximate)	6.17 lb
Ethernet Technology	Gigabit Ethernet10 Gigabit Ethernet
Media Type Supported	Twisted PairOptical Fiber
Network Technology	10GBase-X10GBase-T
Number of Total Expansion Slots	4
Number of SFP+ Slots	4
Shared SFP Slot	No
Expansion Slot Type	SFP+
Modular	Yes
Uplink Port	Yes
Stack Port	Yes
Total Number of Network Ports	12
Port/Expansion Slot Details	12 x 10 Gigabit Ethernet Network4 x 10 Gigabit Ethernet Expansion Slot
Redundant Power Supply Supported	No
Power Source	Power Supply
Layer Supported	3
