APC Smart-UPS VT 20 kVA Tower UPS SUVTP20KF3B4S

Smart-UPS VT offers centralized three-phase power protection with the reliability of the award winning Smart-UPS family. Ideal for small data centers, large retail stores, regional offices, and dense power requirements, the Smart-UPS VT includes dual-mains input, automatic and maintenance bypasses, and scalable runtime with hot-swappable batteries for increased availability. The rack mounted version maximizes valuable floor space by incorporating UPS, power distribution, and additional battery capacity in a single rack. Low cost of ownership is achieved through best-in-class efficiency and a reduction in rating of electrical infrastructure - wires, transformers, and generators due the Smart-UPS VT's Soft Start feature.

Product Type	Dual Conversion Online UPS
Product Series	VT
Brand Name	APC
Manufacturer	American Power Conversion Corp
Product Model	SUVTP20KF3B4S
Product Name	Smart-UPS VT SUVTP20KF3B4S 20 kVA Tower UPS
Product Line	Smart-UPS
Manufacturer Part Number	SUVTP20KF3B4S
Manufacturer Website Address	http://www.apc.com
Batteries	Valve-regulated Lead Acid (VRLA) User Replaceable Hot-swappable
Backup/Run Time	0.20 Hour 16 kW Full Load0.52 Hour 8 kW Half Load
Battery Recharge Time	5 Hour Typical
Height	59"
Width	20.6"
Depth	32"
Form Factor	Tower
Weight (Approximate)	1181 lb
Receptacles	1 x Screw Terminal1 x Hardwired 3PH + N + G
Plug/Connector Type	Hardwired 3PH + N + G
Interfaces/Ports	DB-9 RS-232
Input Voltage Range	208 V AC 3-phase Nominal165 V AC to 240 V AC Mains Operation
Load Capacity	20 kVA/16 kW
Input Voltage	220 V AC
Output Voltage	120 V AC Nominal208 V AC Nominal208 V AC 3-phase Nominal
Network Management	Included
Package Contents	Smart-UPS VT SUVTP20KF3B4S 20 kVA Tower UPS 3 x Battery Modules ship installed Bolt Down Brackets CD with Software Installation Guide Network Management Card Power Modules ship installed Smart UPS Signalling RS-232 Cable Start Up Service User Manual
Limited Warranty	1 Year
