APC Symmetra PX 30kVA Tower UPS SY30K100F

The APC Symmetra PX is a world class, redundant, scalable, power protection system designed to cost effectively provide high levels of availability. Seamlessly integrating into today's state-of-the-art data center designs, the Symmetra PX is a true modular system. Made up of dedicated and redundant modules--power, intelligence, battery and bypass, all engineered into a design that is easily and efficiently serviceable, this architecture can scale power and runtime as demand grows or as higher levels of availability are required. Symmetra PX serves as the core power train that drives APC InfraStruXure systems for small and medium data centers but can also power individual "zones" of larger data centers. Highly manageable, the Symmetra PX features self-diagnostic capabilities and standardized modules which mitigate the risk of human error resulting in increased overall data center reliability.

Product Type	Dual Conversion Online UPS
Product Series	PX
Brand Name	APC
Manufacturer	American Power Conversion Corp
Product Model	SY30K100F
Product Name	Symmetra PX SY30K100F 30kVA Tower UPS
Product Line	Symmetra
Manufacturer Part Number	SY30K100F
Manufacturer Website Address	http://www.apc.com
Batteries	Valve-regulated Lead Acid (VRLA) User Replaceable Hot-swappable
Backup/Run Time	0.10 Hour 30 kW Full Load
Battery Recharge Time	2 Hour Typical
Height	79.2"
Width	47.2"
Depth	42.1"
Form Factor	Tower
Weight (Approximate)	2269.60 lb
Receptacles	1 x Hard Wire 5-wire 3PH + N + G
Input Voltage Range	208 V AC 3-phase Nominal177 V AC to 239 V AC Mains Operation
Load Capacity	30 kVA/30 kW
Input Voltage	220 V AC
Output Voltage	208 V AC 3-phase Nominal
Network Management	SNMP Manageable Included
Package Contents	Symmetra PX SY30K100F 30kVA Tower UPS Installation Guide Network Management Card User Manual 3 x Battery Modules
Limited Warranty	1 Year
