APC by Schneider Electric Galaxy VS UPS 100kW 480V for External Batteries, Start-up 5x8 GVSUPS100KGS

APC by Schneider Electric Galaxy VS UPS 100kW 480V for External Batteries, Start-up 5x8 GVSUPS100KGS
Price $34,306.94
Manufacturer: APC by Schneider Electric
Mfg Number: GVSUPS100KGS
SKU:
Condition: New
Accessories
Description
Highly efficient 20 to 150 kW (480 V), 10 to 150 kW (400 V), and 10 to 75 kW (208 V) 3-phase UPS for edge, small, and medium data centers and other business-critical applications. Galaxy VS is a highly efficient, modular, easy-to-deploy 20 to 150 kW (480 V), 10 to 150 kW (400 V), and 10 to 75 kW (208 V), three-phase uninterruptible power supply that delivers top performance for edge, small, and medium data centers, as well as critical infrastructure in commercial and industrial facilities. Its compact design, high-density technology, N+1 redundancy, and fault-tolerant architecture maximize availability, operational efficiency, and critical load protection, while minimizing total cost of ownership. Thanks to patented technologies, this UPS delivers up to 97% efficiency in normal operating mode and up to 99% in ECOnversion mode, equivalent to 66% higher energy savings. Galaxy VS is EcoStruxure connected to give you peace of mind anytime, anywhere. Smart modular batteries integrated in the UPS cabinet optimize footprint and ensure critical loads have highly predictable runtimes. Start-up service is included to optimize your system's performance, quality, and safety. With its robust design and industry-leading performance, Galaxy VS is the ideal backbone for your critical infrastructure.
Specifications
DC System Voltage 576 V DC
Thermal Dissipation 2783.88 W
Maximum Operating Temperature 104°F (40°C)
Maximum Operating Elevation 3281 ft
Maximum Storage Elevation 50000 ft
Storage Temperature -13°F (-25°C) - 131°F (55°C)
Sound Emission (A-Weighted) 61 dB(A)
Product Type Double Conversion Online UPS
Manufacturer Part Number GVSUPS100KGS
Manufacturer Website Address http://www.schneider-electric.com
Manufacturer Schneider Electric SA
Product Name Galaxy VS UPS 100kW 480V for External Batteries, Start-up 5x8
Product Line Galaxy VS
Brand Name APC by Schneider Electric
Network Management Web/SNMP/Modbus TCP Modbus RTU
Package Contents
  • Galaxy VS UPS 100kW 480V for External Batteries, Start-up 5x8
  • Dust filter
  • Installation guide
  • Integrated network management
  • Power modules
  • Start-up service
  • Top and bottom cable entry
Energy Star Yes
Weight (Approximate) 551.16 lb
Form Factor Tower
Height 58.5"
Width 20.5"
Depth 33.3"
Input Voltage 480 V AC
Output Voltage 480 V AC
Load Capacity 100 kVA
Waveform Type Sine Wave
Output Frequency 60 Hz
Input Frequency 70 Hz
Application/Usage Data Center Commercial Industrial
Overload Protection Yes
Plug/Connector Type Hard Wire 4-wire (3P + E)
Phase Three Phase
Receptacle Type Hard Wire 4-wire (3P + E) Hard Wire 5-wire (3P + N + E)
Receptacle Detail 1 x Hard Wire 4-wire (3P + E) 1 x Hard Wire 5-wire (3P + N + E)
Limited Warranty 1 Year
