APC Smart-UPS VT 20kVA Rack-mountable UPS SUVTR20KF3B5S

Over 10 million installed - now available in three-phase! Smart-UPS VT SUVTR20KF3B5S offers centralized three-phase power protection with the reliability of the award winning Smart-UPS family. Ideal for small data centers, large retail stores, regional offices, and dense power requirements. The rack mounted version maximizes valuable floor space by incorporating UPS, power distribution, and additional battery capacity in a single rack. Low cost of ownership is achieved through best-in-class efficiency and a reduction in rating of electrical infrastructure - wires, transformers, and generators due its soft start feature. The APC Network Management Card with temperature monitoring provides remote monitoring and management through a simple Web/SNMP interface and provides integration with InfraStruXure Manager. All these features make it the easiest UPS in its class to deploy, manage and maintain.

Product Type	Dual Conversion Online UPS
Product Series	VT
Brand Name	APC
Manufacturer	American Power Conversion Corp
Product Name	Smart-UPS VT 20kVA Rack-mountable UPS
Product Line	Smart-UPS
Manufacturer Part Number	SUVTR20KF3B5S
Manufacturer Website Address	http://www.apc.com
Batteries	Valve-regulated Lead Acid (VRLA)
Backup/Run Time	0.19 Hour 16 kW Full Load0.52 Hour 8 kW Half Load
Battery Recharge Time	3 Hour Typical
Height	78.5"
Width	23.6"
Depth	42"
Form Factor	Rack-mountable
Weight (Approximate)	1444 lb
Receptacles	1 x Hard Wire 5-wire 3PH + N + G - Backup/Surge-protected5 x NEMA L21-20 - Backup/Surge-protected
Plug/Connector Type	Hard Wire 5-wire 3PH + N + G
Input Voltage Range	208 V AC 3-phase Nominal165 V AC to 240 V AC Mains Operation
Load Capacity	20 kVA/16 kW
Input Voltage	220 V AC
Output Voltage	120 V AC Nominal208 V AC 3-phase Nominal
Network Management	SNMP Manageable Included
Package Contents	Smart-UPS VT 20kVA Rack-mountable UPS CD with software Installation Guide Power modules ship installed Smart UPS signalling RS-232 cable Start up included User Manual Web/SNMP Management Card
Limited Warranty	1 Year
