Aruba Indoor MIMO 2.4- 2.5 GHZ and 4.9-5.9 GHZ Ceiling Mount Antenna JW001A AP-ANT

AP-ANT-13B antenna offers characteristics that are only normally seen in much larger antennas, offering "no compromise" coverage ideally suited for high-density AP deployments. The AP-ANT-13B antenna features a discrete, small package that easily blends into the office environment and its well-defined coverage area ensures excellent system-wide in-building performance in high-density, high-capacity environments. Ideal for conference rooms, dense cubicle deployments. The AP-ANT-13B is available as a single antenna or a multipack three antenna kit, the AP-ANT-13B-KIT. An array of three AP-ANT-13Bs can be used with a single AP-124 to provide full dual-band 802.11a/b/g/n MIMO coverage, or the AP-ANT-13B single antenna can be used individually or in combination to provide diversity/non-diversity coverage with legacy 802.11a/b/g access points.

Connector Type	RP-SMA
Product Type	Antenna
Brand Name	Aruba
Manufacturer	Hewlett Packard Enterprise
Product Model	AP-ANT-13B
Product Name	Indoor MIMO 2.4- 2.5 GHZ and 4.9-5.9 GHZ Ceiling Mount Antenna
Manufacturer Part Number	JW001A
Manufacturer Website Address	http://www.hpe.com
Application/Usage	IndoorWireless Data NetworkWireless Access Point
Package Contents	Indoor MIMO 2.4- 2.5 GHZ and 4.9-5.9 GHZ Ceiling Mount Antenna Ceiling 15/16" T-bar mounting clips
Height	2.2"
Width	2.2"
Depth	0.6"
Form Factor	Ceiling Mount
Antenna Gain	4 dBi
Directivity	Omni-directional
Frequency	2.40 GHz to 2.50 GHz4.90 GHz to 5.90 GHz
