Aten 4-Port USB HDMI Multi-View KVMP Switch CM1284

Aten 4-Port USB HDMI Multi-View KVMP Switch CM1284
Price $2,651.57
Manufacturer: Aten
Mfg Number: CM1284
SKU:
Condition: New
UPC: 672792009471
Accessories
Description
ATEN CM1284 4-Port USB HDMI Multi-View KVMP™ Switch improves the operational efficiency of real-time monitoring. The CM1284 allows users to manage the data more efficiently by allowing multiple sources to be selected, switched, and displayed at the same time with independent keyboard and mouse control. Advanced video support provides a better-defined HDMI connection with video resolutions up to 4K (4096 x 2160 @ 30 Hz). The CM1284 guarantees users a real-time monitoring functionality by offering dual outputs on console side. One provides the following display modes: Quad View, Picture in Picture (PiP), Picture by Picture (PbP), Picture on Picture (PoP), and the other one provides Full Screen mode. Featuring Boundless Switching, the CM1284 allows users to simply move the mouse cursor across windows to switch to other video sources. This makes it easier to instantly access and control the target computer.Incorporating Daisy Chain Control (DCC) capability, users are allowed to control up to 3 additional CM1284 units via a single console. In addition, CM1284 can be cascaded up to 2 levels to reach the maximum of 16 video sources to be simultaneously selected, switched, and displayed with independent keyboard and mouse control. Engineered to meet the ever-increasing demand for multi-view functionality, the CM1284 is specifically designed for where real-time monitoring is needed such as aviation industry, financial trading, and medical application.
Specifications
Product TypeKVM Switchbox
Brand NameATEN
ManufacturerATEN Technology Inc
Product ModelCM1284
Product NameCM1284 4-Port USB HDMI Multi-View KVMP Switch
Manufacturer Part NumberCM1284
Manufacturer Website Addresshttp://www.aten-usa.com
Packaged Quantity1
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
Package Contents
  • CM1284 4-Port USB HDMI Multi-View KVMP Switch
  • 4 x USB HDMI Cables
  • 1 x Power Cord
  • 1 x IR Remote Control
  • 1 x Rack Mount Kit
  • 1 x User Instructions
Maximum Video Resolution4096 x 2160
USBYes
HDMIYes
Number of HDMI Ports6
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of USB Ports8
Number of Computers Supported4
Number of Local Users Supported2
Height1.7"
Width17.2"
Depth6.5"
Form FactorDesktopRack-mountable
Weight (Approximate)5.42 lb
Input Voltage Range100 V AC - 240 V AC
Limited Warranty3 Year
