Aten 32x32 Modular Matrix Switch VM3200

The VM3200 Modular Matrix Switch offers advanced access and real-time control of multiple local and remote A/V input devices and displays from a single chassis. The VM3200 allows users to independently switch and route video and/or audio content directly to various monitors, displays, projectors, and/or speakers simply by pressing front panel pushbuttons. A built-in Scaler encodes the video format in order to provide seamless, real-time switching. The front panel LCD shows a quick view of active port connections. The switch also includes an option to select an EDID Mode that yields the best resolution across different monitors. The VM3200 is easily expandable and accommodates a lineup of hot-swappable ATEN I/O boards. Equipped with automatic signal conversion, it allows various combinations of digital video interfaces, including HDBaseT (VM7514 / VM8514), HDMI (VM7804 / VM8804), DVI (VM7604 / VM8604), 3G-SDI (VM7404), and VGA (VM7104). This makes it ideal for large-scale A/V applications such as broadcasting stations, traffic and transportation-related control rooms, emergency service centers, and any application that requires customizable, high-speed A/V signal routing.

Product Type	Audio/Video Switchbox
Brand Name	Aten
Manufacturer	Aten Technologies
Product Model	VM3200
Product Name	32x32 Modular Matrix Switch
Product Line	VanCryst
Manufacturer Part Number	VM3200
Manufacturer Website Address	http://www.aten-usa.com
Packaged Quantity	1
Graphics Modes	4K
Maximum Video Resolution	4096 x 2160
Environmentally Friendly	Yes
Environmental Certification	RoHSWEEE
Package Contents	32x32 Modular Matrix Switch 1 x Power Cord 1 x Terminal Block Connector 1 x User Instructions
Media Type Supported	Twisted Pair
Number of Displays Supported	32
Number of Input Devices Supported	32
Connectivity Technology	Cable
Device Supported	Display
Connectivity (RJ-45)	Yes
Number of Connectivity (RJ-45) Ports	1
Height	15.7"
Width	18.6"
Depth	19"
Form Factor	Rack-mountable
Weight (Approximate)	40.12 lb
Limited Warranty	3 Year
