Aten 32 x 32 Modular Matrix Switch Gen.2 VM3250

The VM3250 Modular Matrix Switch Gen. 2 offers advanced access and real-time control of multiple local and remote A/V input devices and displays from a single chassis. The VM3250 allows users to independently switch and route video and/or audio content directly to various monitors, displays, projectors, and/or speakers from the front panel pushbuttons. A built-in Scaler encodes the video format in order to provide seamless, real-time switching. The front panel LCD shows a quick view of active port connections. The switch also includes an option to select an EDID Mode that yields the best resolution across different monitors. Boasting a sophisticated and reliable design that delivers the best audio/visual distribution and control, the solution also incorporates an Award-winning GUI that can be accessed from anywhere over a network or the internet. Through the intuitive web interface, video sources can be previewed in real-time via live streaming and video walls can be easily set up. A calendar-based scheduling function allows you to queue and play connection profiles via a calendar view for a set period of time, reducing related operation costs. The VM3250 is easily expandable and accommodates a lineup of hot-swappable ATEN I/O boards. Equipped with automatic signal conversion, it allows various combinations of digital and analog video interfaces, including Fiber Optic, HDBaseT, DisplayPort, HDMI, DVI, 3G-SDI, and VGA. The flexibility and expandability make it ideal for large-scale A/V applications such as broadcasting stations, traffic and transportation-related control rooms, emergency service centers, and any application that requires customizable, high-speed A/V signal routing.

Connectivity (RJ-45)	Yes
Number of Connectivity (RJ-45) Ports	1
Product Type	Audio/Video Switchbox
Manufacturer Part Number	VM3250
Manufacturer Website Address	http://www.aten.com/us/en/
Packaged Quantity	1
Manufacturer	ATEN Technology, Inc
Product Model	VM3250
Product Name	32 x 32 Modular Matrix Switch Gen.2
Brand Name	ATEN
Media Type Supported	Twisted Pair
Package Contents	32 x 32 Modular Matrix Switch Gen.2 1 x Power Module 1 x Terminal Block Connector 1 x Power Cord 1 x User Instructions
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
Weight (Approximate)	40.12 lb
Height	15.7"
Width	19"
Depth	18.6"
Device Supported	Display
Connectivity Technology	Cable
Number of Displays Supported	32
Number of Input Devices Supported	32
Graphics Modes	4K
Maximum Video Resolution	4096 x 2160
Limited Warranty	3 Year
