Aten 8 x 9 4K HDMI Matrix Switch with Scaler VM6809H

Aten 8 x 9 4K HDMI Matrix Switch with Scaler VM6809H
$11008.67
Manufacturer: Aten
Mfg Number: VM6809H
SKU:
Condition: New
UPC: 672792008283
Accessories
Description
4K is the next generation of image quality for high definition video, which delivers eight million pixels that is four times as much detail as 1080p Full HD resolutions. ATEN's VM6809H 4K HDMI Matrix Switch with Scaler is compatible with the two latest 4K video resolution standards: 3840 x 2160 and 4096 x 2160. The VM6809H offers powerful HD processing to produce 4K resolutions across nine displays with crystal-clear images. The VM6809H supports 4K @ 60 Hz, HDMI 2.0 and HDCP 2.2 and features seamless switching that employs an FPGA matrix architecture that ensures continuous video streams, real-time control, and stable signal transmissions. With a built-in high-performance scaler, the VM6809H easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy-to-use web GUI that lets you create 17 connection profiles that can be customized into different video wall layouts. The VM6809H is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently setup - such as for stage presentations, digital classroom, video conference rooms and any installation that requires real-time synchronization.
Specifications
Product TypeAudio/Video Switchbox
Brand NameAten
ManufacturerAten Technologies
Product ModelVM6809H
Product Name8 x 9 4K HDMI Matrix Switch with Scaler
Product LineVanCryst
Manufacturer Part NumberVM6809H
Manufacturer Website Addresshttp://www.aten-usa.com
Packaged Quantity1
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
Package Contents
  • 8 x 9 4K HDMI Matrix Switch with Scaler
  • 1 x Power Cord
  • 1 x Rack Mounting Kit
  • 1 x User Instructions
Maximum Operating Distance49.21 ft
Number of HDMI Inputs8
Number of HDMI Outputs9
HDMI InYes
HDMI OutYes
Connectivity (RJ-45)Yes
Number of Connectivity (RJ-45) Ports1
Number of Displays Supported8
Number of Input Devices Supported8
Connectivity TechnologyCable
Device SupportedDisplay
Height1.7"
Width17.7"
Depth17"
Form FactorRack-mountable
Weight (Approximate)15.54 lb
Limited Warranty3 Year
