Aten 4 x 2 True 4K Presentation Matrix Switch with Scaling, DSP, and HDBaseT-Lite VP1421

The VP1421 is a multi-in-one presentation switch that integrates a video matrix, True 4K scaler, HDBaseT extender, audio DSP, and analog-to-digital converter functions into a single compact enclosure, ideal for meeting rooms and educational spaces. True 4K, HDR Visual Clarity Supports resolutions up to 4096 x 2160 @ 60Hz (4:4:4) and HDR to deliver vivid content in every presentation. Smooth AV Switching Scaled to Perfection Connect up to 4 sources (1 HDBaseT, 2 HDMI, 1 VGA), smoothly switch between them and display contents scaled perfectly to True 4K and 1080p simultaneously. HDBaseT Extended Transmission over One Cable Simplifies cabling and transmits AV, power, and bi-directional RS-232 and IR control signals up to 140m via Cat 6/6a or ATEN 2L-2910 Cat 6 cables (applying both HDBaseT input and output ports). Built-in Advanced Audio DSP Supports microphone input with selectable 48V Phantom Power and allows microphone input to be mixed with program audio and embedded into display output while automatically reducing program audio to enhance speech audibility. Flexible Audio Embedding/De-Embedding Supports stereo audio embedding into HDMI output or separation to Audio Line Out and Optical Audio Out. Extract HDMI and HDBaseT audio to different audio outputs as well to ease adaptation to you preferred audio setup. Versatile Control, Streamlined Operations Control via front-panel pushbuttons, IR remote, web-based GUI and any control interface via RS-232, Ethernet, and Contact Closure to streamline your operations.

Number of HDMI Inputs	2
Number of HDMI Outputs	1
VGA In	Yes
HDMI In	Yes
HDMI Out	Yes
Number of VGA Inputs	1
Product Type	Audio/Video Switchbox
Manufacturer Part Number	VP1421
Manufacturer Website Address	http://www.aten.com/us/en/
Packaged Quantity	1
Manufacturer	ATEN Technology, Inc
Product Model	VP1421
Product Name	4 x 2 True 4K Presentation Matrix Switch with Scaling, DSP, and HDBaseT-Lite
Brand Name	ATEN
Maximum Operating Distance	459.32 ft
Media Type Supported	Twisted Pair
Package Contents	4 x 2 True 4K Presentation Matrix Switch with Scaling, DSP, and HDBaseT-Lite 1x IR Receiver 1x IR Remote Control 4x 3-pole Terminal Blocks 2x 5-pole Terminal Blocks 1x Power Adapter 1x User Instructions
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
Weight (Approximate)	2.56 lb
Form Factor	Under Table Rack-mountable
Height	1.7"
Width	6.7"
Depth	7.9"
Device Supported	Notebook Media Player
Connectivity Technology	Cable
Number of Displays Supported	2
Number of Input Devices Supported	4
Graphics Modes	4K
Maximum Video Resolution	4096 x 2160
