Black Box KVM Extender ACX1T-12A-SM

DescriptionDKM HD Video and Peripheral Matrix Switch Compact Transmitter, Fiber, Single DVI-D Plus (4) USB HIDQuick FactsConnect users and computers to the DKM HD Video and Peripheral Matrix Switch, while extending them simultaneously over long distances.Order one transmitter for each computer connected to the DKM.Use one receiver for each user within the DKM system.Further DetailsThe fiber-compatible extenders can be used with multimode or single-mode fiber optic cable.Maximum distance over multimode fiber is 3281 feet (1000 m).Maximum distance over single-mode fiber is 6 miles (10 km).Also available in models compatible with CATx cable.Compact housing enables high-density mounting within 19" racks (up to four devices in 1U).Chassis range in size from 2, 4, 6, or 21 ports, to 48, 80, 160, and 288 ports.The compact extenders also work as standalone, point-to-point KVM extenders.

Product Type	KVM Extender
Brand Name	Black Box
Manufacturer	Black Box Corporation
Product Name	KVM Extender
Manufacturer Part Number	ACX1T-12A-SM
Manufacturer Website Address	http://www.blackbox.com
Maximum Video Resolution	1920 x 1200
Graphic Mode	WUXGA
Maximum Operating Distance	32808.40 ft
Number of Computers Supported	1
Connectivity Technology	Wired
USB	Yes
DVI	Yes
Number of USB Ports	4
Number of DVI Ports	1
Form Factor	Rack-mountable
