Black Box Transceiver/Media Converter LBH2001A-H-LX

This compact networking device combines the functions of a copper-to-fiber media converter with that of a Gigabit-speed edge switch. Featuring the two 10-/100-/1000-Mbps copper switch ports and one 1000-Mbps single-mode fiber LC port, the Hardened Media Converter Switch reliably connects segments in harsh factory floor environments, particularly at the network edge, as well as connections in wiring closet and office areas. It's just what you need to expand your Ethernet network in a convenient, compact, and economical way-plus transfer data longer distances, far beyond what's possible with ordinary copper Ethernet cabling links. And because it transfers Ethernet packets at Gigabit speeds over fiber, you can ensure secure and interference-free extensions for your data-sensitive, bandwidth-intensive applications. What's more, as a hardened networking solution, it features a sealed metal case that protects internal circuitry from dirt, dust, moisture, and other harmful contaminants. The Hardened Media Converter Switch also features an efficient thermal design, so no air inflow is required for cooling.

Product Type	Transceiver/Media Converter
Brand Name	Black Box
Manufacturer	Black Box Corporation
Product Model	LBH2001A-H-LX
Product Name	LBH2001A-H-LX Transceiver/Media Converter
Manufacturer Part Number	LBH2001A-H-LX
Manufacturer Website Address	http://www.blackbox.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHSWEEE
Country of Origin	United States
Package Contents	LBH2001A-H-LX Transceiver/Media Converter Metal Panel Mounting Clips
Ethernet Technology	Gigabit Ethernet
Network Technology	1000Base-LX1000Base-T
USB	No
DVI	No
Number of Network (RJ-45) Ports	2
Network (RJ-45)	Yes
Management Port	No
Number of LC Ports	1
Total Number of Ports	3
Media Type Supported	Optical FiberTwisted Pair
Fiber Mode Supported	Single-mode
Fiber Optic Wavelength	1310 nm
Maximum Distance Supported	6.21 Mile
Height	3.5"
Width	3"
Depth	1"
Form Factor	Rail-mountableRack-mountable
Weight (Approximate)	4.80 oz
Limited Warranty	3 Year
