Black Box ServSwitch KM Switchbox SW2006A-USB-EAL

DescriptionServSwitch Secure KVM Switch with USB, EAL2+ EAL4+ Certified/TEMPEST Level I (Level A) Qualified, VGA, 2-PortQuick FactsGet a high level of port-to-port electrical isolation, which facilitates data separation (RED/BLACK).Channel-to-channel 80-dB crosstalk isolation protects against signal snooping.Permanently hard wired, preventing access from one CPU or network to the others.Now listed on NIAP website.Further DetailsThe low radiated emissions profile meets the appropriate national requirements.External tamper-evident seals.Provides robust isolation between networks, so it's ideal for government applications that access classified networks in addition to public networks such as the Internet.Constructed with a solid metal case and a long-wearing switching mechanism.USB host controller erases entire RAM to prevent residual data remaining on channel.Dedicated DDC bus and EDID memory emulation at each port.Clear, unmistakable channel selection.Non-Flash-upgradable ROM.To minimize electronic signaling, no common power supply. The ServSwitch™ Secure KVM Switch with USB, EAL4+ Certified/TEMPEST Level I (Level A) Qualified, VGA, surpasses the security profiles of most other KVM switches. In addition to its superior hardware-based data-isolation features, the switch has been certified for Common Criteria Evaluation Assurance to Level 4+ (EAL4+), augmented by ALC_FLR.2 and ATE_DPT.2. The Common Criteria is an international standardized process for information technology security evaluation, validation, and certification. The Common Criteria scheme is supported by the National Security Agency through the National Information Assurance Program (NIAP). EAL4+ itself defines a common set of tests to evaluate the security of an IT product relating to its supply chain, from design and engineering to manufacturing and distribution.

Product Type	KM Switchbox
Brand Name	Black Box
Manufacturer	Black Box Corporation
Product Name	ServSwitch KM Switchbox
Product Line	ServSwitch
Manufacturer Part Number	SW2006A-USB-EAL
Manufacturer Website Address	http://www.blackbox.com
Packaged Quantity	1
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Maximum Video Resolution	1920 x 1280
USB	Yes
VGA	Yes
Number of USB Ports	3
Number of VGA Ports	1
Number of Computers Supported	2
Number of Local Users Supported	1
Height	1.8"
Width	9.3"
Depth	5.9"
Weight (Approximate)	1.10 lb
Limited Warranty	2 Year
