Cisco UCS C240 M5 Barebone System HX-C240-M5L

The UCS C240 M5 LFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666-MHz or 2933-MHz DIMMs with capacity points up to 128 GB, 2666-MHz DCPMMs with capacity points up to 512 GB, up to 6 PCI Express (PCIe) 3.0 slots, and up to 12 front-facing internal LFF drives. The C240 M5 LFF server also includes one dedicated internal slot for a 12G SAS storage controller card.The latest update includes support for 2nd Generation Intel® Xeon® Scalable Processors, 2933-MHz DDR4 memory, and the new 512GB Intel® OptaneTM DC Persistent Memory Modules (DCPMMs). With this combination of features, up to 9 TB of memory is possible (using 12 x 256 GB DDR4 DIMMs and 12 x 512 GB DCPMMs).The C240 M5 server includes a dedicated modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC) without consuming a PCI slot, in addition to 2 x 10 Intel x550 10Gbase-T embedded (on the motherboard) LOM ports.The Cisco UCS C240 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.

Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Controller Type	12Gb/s SAS
RAID Supported	Yes
Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200e
Graphics Memory Capacity	8 MB
Product Type	Barebone System
Manufacturer Part Number	HX-C240-M5L
Manufacturer Website Address	http://www.cisco.com
Manufacturer	Cisco Systems, Inc
Product Name	UCS C240 M5 Barebone System
Product Series	C240 M5
Brand Name	Cisco
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	14
Number of 3.5" Bays	12
Maximum Memory Supported	9 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2933/PC4-23466
Number of Total Memory Slots	24
Intel Optane Memory Ready	Yes
Environmentally Friendly	Yes
Environmental Certification	EPEAT Bronze
Ethernet Technology	10 Gigabit Ethernet Gigabit Ethernet
Weight (Approximate)	66 lb
Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	19"
Depth	30.2"
Product Color	Gray Silver
Input Voltage	120 V AC 230 V AC
Optical Drive Type	No
Limited Warranty	3 Year
Processor Supported	Xeon Platinum Xeon Gold Xeon Silver Xeon Bronze
64-bit Processing	Yes
Number of Processors Supported	2
Chipset Manufacturer	Intel
Chipset Model	C620
