Cisco Catalyst Rugged Switch IE-3200-8P2S-E IE-3200-8P2S

The Cisco Catalyst IE3200 Rugged Series delivers high-speed Gigabit Ethernet connectivity in a compact form factor and is designed for a wide range of industrial applications where hardened products are required. The platform is built to withstand harsh environments in manufacturing, energy, transportation, mining, smart cities, and oil and gas. The IE3200 platform is also ideal for extended enterprise deployments in outdoor spaces, warehouses, and distribution centers. These switches run Cisco IOS® XE, a next-generation operating system with built-in security and trust, featuring secure boot, image signing, and a Cisco® Trust anchor module. Cisco IOS XE also provides API-driven configuration with open APIs and data models. The Cisco Catalyst IE3200 Rugged Series can be managed with powerful management tools such as Cisco DNA Center and Industrial Network Director, and can be easily set up with a completely redesigned, user-friendly, modern GUI tool called WebUI. The IE3200 Series provides an option for up to eight ports of Power over Ethernet Plus (PoE+), with a product SKU that is ideal for connecting PoE-powered end devices such as IP cameras, phones, wireless access points, sensors, and more.

Product Type	Ethernet Switch
Product Series	IE3200
Brand Name	Cisco
Manufacturer	Cisco Systems, Inc
Product Model	IE-3200-8P2S
Product Name	Catalyst IE-3200-8P2S Rugged Switch
Product Line	Catalyst
Manufacturer Part Number	IE-3200-8P2S-E
Manufacturer Website Address	http://www.cisco.com
Manageable	Yes
Ethernet Technology	Gigabit Ethernet
Media Type Supported	Twisted PairOptical Fiber
Network Technology	10/100/1000Base-T1000Base-X
Number of Total Expansion Slots	2
Number of SFP Slots	2
Shared SFP Slot	No
Expansion Slot Type	SFP (mini-GBIC)
Modular	Yes
Total Number of Network Ports	8
Port/Expansion Slot Details	8 x Gigabit Ethernet Network2 x Gigabit Ethernet Expansion Slot
Redundant Power Supply Supported	Yes
Power Source	Power Supply
Height	6"
Width	3.6"
Depth	5.3"
Form Factor	DIN Rail Mountable
Weight (Approximate)	3.75 lb
Layer Supported	3
