Cisco SmartPlay Select S3260 Basic UCSS-SP-S3260-BB

The Cisco UCS S3260 helps you achieve the highest levels of performance and capacity. With dual-node capability that is based on the Intel® Xeon® processor E5-2650 v4 series, it features up to 84 TB of local storage in a compact 4-rack-unit (4RU) form factor. The drives can be configured with enterprise-class Redundant Array of Independent Disks (RAID) redundancy or as JBOD in pass-through mode. Network connectivity provided with dual port 40G per server nodes with expanded unified I/O capabilities for connectivity between NAS and SAN environments. This high-capacity storage server comfortably fits in a standard 32-inch depth rack, such as the Cisco® R42610 Rack.

Fibre Channel	Yes
Network (RJ-45)	Yes
Total Number of USB Ports	1
Number of USB 3.0 Ports	1
Drive Interface	12Gb/s SAS
RAID Levels	0, 1, 5, 6, 10, 50, 60, JBOD
Controller Type	12Gb/s SAS
Number of Controllers	1
RAID Supported	Yes
Product Type	NAS Storage System
Manufacturer Part Number	UCSS-SP-S3260-BB
Manufacturer Website Address	http://www.cisco.com
Manufacturer	Cisco Systems, Inc
Product Name	SmartPlay Select S3260 Basic
Product Series	S3260 M4
Brand Name	Cisco
Expansion Slot Type	QSFP+
Number of Total Expansion Bays	60
Number of 3.5" Bays	60
Number of Total Expansion Slots	3
Standard Memory	128 GB
Memory Technology	DDR4 SDRAM
Ethernet Technology	40 Gigabit Ethernet
Weight (Approximate)	195 lb
Form Factor	Rack-mountable
Rack Height	4U
Height	6.9"
Width	17.5"
Depth	32"
Number of Power Supplies Installed	4
Redundant Power Supply	Yes
Maximum Power Supply Wattage	1050 W
Total Hard Drive Capacity Installed	84 TB
Total Solid State Drive Capacity Supported	84 TB
Number of Hard Drives Supported	60
Number of Hard Drives Installed	14
Number of Solid State Drive Supported	60
Number of Boot Drives	2
Processor Speed	2.20 GHz
Processor Type	Xeon
Processor Model	E5-2650v4
Processor Core	Dodeca-core (12 Core)
Processor Manufacturer	Intel
Number of Nodes	1
Number of Processors Installed	2
Protocols	FCP
Operating System	No
