Dataram 8GB DDR3 SDRAM Memory Module DTI16S2L8W/8G

DTI16S2L8W/8G is an Unbuffered DDR3 1Gx64 small-outline memory module, which conforms to JEDEC's DDR3L, PC3L-12800 standard. The assembly is dual- rank, each rank comprised of eight 512Mx8 DDR3 Industrial Temp SDRAMs. One EEPROM is used for Serial Presence Detect. Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.

Product Type	RAM Module
Manufacturer Part Number	DTI16S2L8W/8G
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	8GB DDR3 SDRAM Memory Module
Brand Name	Dataram
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	240-pin
Thickness	149.6 mil
Form Factor	SoDIMM
Length	2.7"
Width	1.2"
CAS Latency	CL11
Error Checking	Non-ECC
Number of Modules	1 x 8GB
Signal Processing	Unbuffered
Memory Speed	1600 MHz
Memory Size	8 GB
Memory Technology	DDR3 SDRAM
Memory Standard	DDR3-1600/PC3L-12800
Memory Voltage	1.35 V
Limited Warranty	Lifetime
