Dataram 2GB DDR3 SDRAM Memory Module DTM64368D

DTM64368D is an Unbuffered 256Mx64 memory module, which conforms to JEDEC's DDR3, PC3-12800 standard. The assembly is Single-Rank containing: eight 256Mx8 DDR3 Samsung SDRAMs. One 2K-bit EEPROM is used for Serial Presence Detect. Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals.

Product Type	RAM Module
Manufacturer Part Number	DTM64368D
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	2GB DDR3 SDRAM Memory Module
Brand Name	Dataram
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	240-pin
Thickness	157.5 mil
Form Factor	DIMM
Length	5.3"
Width	1.2"
CAS Latency	CL11
Error Checking	ECC
Number of Modules	1 x 2GB
Signal Processing	Unbuffered
Memory Speed	1600 MHz
Memory Size	2 GB
Memory Technology	DDR3 SDRAM
Memory Standard	DDR3-1600/PC3-12800
Memory Voltage	1.50 V
