Dataram 32GB DDR4 SDRAM Memory Module DTM68307-H

DTM68307-H is a load reduced 4Gx72 memory module, which conforms to JEDEC's DDR4-2666, PC4-2666 standard. The assembly is Dual-Rank containing - eighteen SKHynix 2Gbx4 DDR4-2666 SDRAMs. One 4K-bit EEPROM is used for Serial Presence Detect and a Registering Clock Driver, with Address and Command Parity, is also used as well as data buffers to reduce the overall loading on the data bus. Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology. A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C.

Product Type	RAM Module
Manufacturer Part Number	DTM68307-H
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	32GB DDR4 SDRAM Memory Module
Brand Name	Dataram
Country of Origin	United States
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	288-pin
Thickness	156.7 mil
Form Factor	LRDIMM
Length	5.3"
Width	1.2"
CAS Latency	CL19
Device Supported	Server
Error Checking	ECC
Number of Modules	1 x 32GB
Signal Processing	Registered
Memory Speed	2666 MHz
Memory Size	32 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Memory Voltage	1.20 V
Limited Warranty	Lifetime
