Dataram Value Memory 4GB DDR3 SDRAM Memory Module DVM16U2S8/4G

DVM16U2S8/4G is an Unbuffered 512Mx64 memory module, which conforms to JEDEC's DDR3, PC3-12800 standard. The assembly is dual Rank. The rank is comprised of sixteen 256Mx8 DDR3 SDRAMs. One EEPROM is used for Serial Presence Detect. Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.

Product Type	RAM Module
Manufacturer Part Number	DVM16U2S8/4G
Manufacturer Website Address	http://www.dataram.com
Manufacturer	Dataram Corporation
Product Name	Value Memory 4GB DDR3 SDRAM Memory Module
Product Line	Value Memory
Brand Name	Dataram
Environmentally Friendly	Yes
Environmental Certification	RoHS
Number of Pins	240-pin
Thickness	157.5 mil
Form Factor	DIMM
Length	5.3"
Width	1.2"
CAS Latency	CL11
Error Checking	Non-ECC
Number of Modules	1 x 4GB
Signal Processing	Unbuffered
Memory Speed	1600 MHz
Memory Size	4 GB
Memory Technology	DDR3 SDRAM
Memory Standard	DDR3-1600/PC3-12800
Memory Voltage	1.50 V
Limited Warranty	Lifetime
