Electro-Voice EVID- Ceiling Speaker 6.5" White EVID-C6.2 C6.2

Full bandwidth overload protection Front baffle wattage tap adjustment Includes tile bridge and mounting ring for easy installation UL1480A and CSA 22.2 205 certified The Electro-Voice EVID-C6.2 loudspeaker system is a complete two-way ceiling loudspeaker. The package consists of a bezel assembly, grille, rear enclosure, 6.5-inch coax two-way loudspeaker and internal linematching transformer. The loudspeaker features a waveguide coupled titanium coated dome tweeter. The EVID-C6.2 loudspeaker utilizes a 2nd order crossover network at 2.5 kHz, with a comprehensive protection circuit to protect the network, woofer, and tweeter drivers from excessive power levels. The EVID-C6.2 utilizes a transformer that offers a selection of 1.88 (70-V only), 3.75, 7.5, 15W or 30 watts delivered to the loudspeaker system using either 70-V or 100-V lines, or 8 ohm bypass. Selection is via a convenient switch on the front baffle. The perforated grille is finished in semi-gloss white powder-coated enamel. The baffle and bezel are constructed from UL 94V-0 rated ABS. The rear enclosure is constructed from zinc-plated, heavy gauge steel. The low profile enclosure makes it easy to mount in very tight spaces. A rear cover, with provisions for a junction box fitting, provides access to a 4-pin terminal block that allows direct connection to the speaker with 12 gauge wire and provides pass through to additional speakers. A tile bridge is included for safe suspension of the EVID-C6.2 ceiling systems in a drop ceiling that uses mineral wool, or other fiber-based ceiling tiles. The EVID line of ceiling speakers has been designed to work together as a complete system in a wide range of different ceiling constructions. They provide wide dispersion, highefficiency, high-maximum output, ease of installation, and wide-range reproduction of music or voice.

Product Type	Speaker
Manufacturer Part Number	EVID-C6.2
Manufacturer Website Address	http://www.bosch.com
Manufacturer	The Bosch Group
Product Model	C6.2
Product Name	EVID-C6.2 Ceiling Speaker 6.5" White
Product Line	EVID
Brand Name	Electro-Voice
Package Contents	EVID-C6.2 Ceiling Speaker 6.5" White Tile Bridge Mounting Ring
Weight (Approximate)	10 lb
Form Factor	Ceiling Mountable
Diameter	11.8"
Depth	7"
Cutout Diameter	10.60"
Product Color	White
Impedance	8 Ohm
Sensitivity	90 dB
Crossover Type	2-way
Minimum Frequency Response	50 Hz
Maximum Frequency Response	20 kHz
Limited Warranty	3 Year
