Electro-Voice EVU-1082/95 Single 8" Two-Way 90° x 50° Full-Range Loudspeaker System EVU-1082

General Description:The Electro-Voice EVU-1082/95 is a compact two-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in an ultra-compact lightweight enclosure. The enclosure design utilizes asymmetric angles to maintain tight clearances to wall and ceilings while providing optimal coverage patterns making it ideal to blend into surroundings. This design was optimized for wall, stage lip and under balcony applications.The EVU-1082/95 incorporates the ICT-1-8, a high-output 1.3" diaphragm titanium compression driver coupled to a Constant Directivity™ 90° x 50° rotatable waveguide. The ICT-8-8 woofer was developed using FEA optimization to provide the highest sensitivity while achieving the highest level of speech intelligibility. The crossover design uses 18-dB-per-octave slopes with equalization for very smooth response in the vocal range, linear off-axis response and a protection circuit for long term reliability.The EVU series is constructed of 9-ply hardwood plywood enclosures with six integral M8 suspension points to support a wide variety of mounting positions. The EVU system is finished in textured paint, available in either white or black. Each EVU system includes a universal U-bracket to facilitate mounting. The U-bracket provides full unobstructed rotation of the loudspeaker (330° unobstructed rotation if the transformer kit is installed). Additional mounting points are located on the rear of the enclosure for use with an Omnimount™ type bracket. An available 70.7/100-V transformer kit may be easily mounted over the input panel for use in distributed systems. All of these features give you the flexibility to address a large range of venues, while quickly and precisely supporting customer requirements.

Product Type	Speaker
Manufacturer Part Number	EVU-1082/95-WHT
Manufacturer Website Address	http://www.bosch.com
Manufacturer	The Bosch Group
Product Name	EVU-1082/95 Single 8" Two-Way 90° x 50° Full-Range Loudspeaker System
Product Series	EVU
Brand Name	Electro-Voice
Package Contents	EVU-1082/95 Single 8" Two-Way 90° x 50° Full-Range Loudspeaker System Universal U-bracket
Weight (Approximate)	16.30 lb
Form Factor	Ceiling Mountable Wall Mountable
Height	9.7"
Width	16.1"
Depth	9.34"
Woofer Diameter	8"
Product Color	White
Impedance	8 Ohm
Sensitivity	123 dB
Crossover Type	2-way
Minimum Frequency Response	65 Hz
Maximum Frequency Response	20 kHz
RMS Output Power	175 W
PMPO Output Power	700 W
Tweeter Driver Size	1.30"
Woofer Driver Size	8"
Tweeter Driver Material	Titanium
