Elo 21.5" Open Frame Touchscreen (Rev B) E327914 2294L

Elo 21.5" Open Frame Touchscreen (Rev B) E327914 2294L
Price $613.27
Manufacturer: Elo
Mfg Number: E327914
SKU:
Model: 2294L
Condition: New
UPC: 815335025860
Accessories
Description
The Elo 2294L 21.5-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 2294L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments.Easily integrated.The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs.Touch ready.Available with a choice of industry-leading touch technologies, in single-, dual- or multi-touch technology, including IntelliTouch® single- and dual-touch surface acoustic wave (SAW), and our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves.Commercial-grade.The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.Other features. High definition LCD display offers ultimate HD interactivity, clarity and resolution 10-touch TouchPro projected capacitive with two-touch Thru-glass capabilities that passes UL-60950 & IK-07 Impact testing Viewing angle of 178° (h) x 178° (v), for sharp colors and graphics in both portrait and landscape modes Display Port and VGA video interfaces
Specifications
Product TypeOpen-frame LCD Touchscreen Monitor
Brand NameElo
ManufacturerElo Touch Solutions, Inc
Product Model2294L
Product Name2294L 21.5" Open Frame Touchscreen (Rev B)
Manufacturer Part NumberE327914
Manufacturer Website Addresshttp://www.elotouch.com
Environmentally FriendlyYes
Environmental CertificationT�VRoHSChina RoHSWEEE
Package Contents
  • 2294L 21.5" Open Frame Touchscreen (Rev B)
  • HDMI cable
  • VGA Cable
  • RJ45 OSD Remote
  • Touch USB Cable
  • User Manual CD
  • Quick Install Guide
  • "L" (Side Mount) Brackets and w/Screws
  • EEI Label
  • Japan Class-B TM info sheet
USBYes
HDMIYes
VGAYes
DisplayPortYes
Backlight TechnologyLED
Screen ModeFull HD
Mount TypeFront MountRack-mountable
Screen Size21.5"
Aspect Ratio16:9
Response Time14 ms
VESA Mount CompatibleYes
Height11.7"
Width20.1"
Depth1.7"
ColorBlack
Weight (Approximate)11.24 lb
Operating Power Consumption25 W
Brightness250 Nit
Color Supported16.7 Million Colors
Maximum Resolution1920 x 1080
Contrast Ratio1,000:1
Limited Warranty3 Year
Touchscreen TypeIntelliTouch Surface Wave
