Extreme Networks Summit Layer 3 Switch 17300 X670-G2-72x

The Summit X670-G2 product family provides high density 10 Gigabit Ethernet and 40 Gigabit Ethernet switching in a small 1RU form factor. With its versatile design, the Summit X670-G2 provides high density Layer 2/3 10Gb networking with low latency cut-through switching, and IPv4 and IPv6 unicast and multicast routing to enable enterprise aggregation and core backbone deployment in AC-powered and DC-powered environments. The Summit X670-G2 simplifies network operation with the ExtremeXOS modular operating system (OS), which is used among all Extreme Networks Summit and BlackDiamond Ethernet switches. The high availability ExtremeXOS operating system provides simplicity and ease of operation through the use of one OS everywhere in the network. The Summit X670-G2 comes in two models: X670-G2-48x-4q - 48 ports of 1/10Gb SFP+ with 4 ports of 10/40Gb QSFP+ X670-G2-72x - 72 ports of 1/10Gb SFP+ in 1 RU form factor The Summit X670-G2-48x-4q supports four QSFP+ ports of 40 GbE. Each 40 Gigabit Ethernet port can be independently configured as 40 Gigabit Ethernet or 4 x 10 Gigabit Ethernet. The X670-G2-72x model supports 72 ports of native 1Gb/10Gb SFP+ ports in a single compact system without the requirement to use break-out cables to achieve high density 10Gb connections.

Modular	Yes
Product Type	Layer 3 Switch
Manufacturer Part Number	17300
Manufacturer Website Address	http://www.extremenetworks.com
Packaged Quantity	1
Manufacturer	Extreme Networks, Inc
Product Model	X670-G2-72x
Product Name	Summit X670-G2-72x Layer 3 Switch
Product Line	Summit
Product Series	X670-G2
Brand Name	Extreme Networks
Expansion Slot Type	SFP+
Number of Total Expansion Slots	72
Number of SFP+ Slots	72
Network Technology	10GBase-X
Ethernet Technology	10 Gigabit Ethernet
Media Type Supported	Optical Fiber
Layer Supported	3
Weight (Approximate)	15.43 lb
Form Factor	Rack-mountable
Height	1.7"
Width	19.2"
Depth	17.4"
Compatible Rack Unit	1U
Power Source	Power Supply
Redundant Power Supply Supported	Yes
Manageable	Yes
Limited Warranty	1 Year
