Geist 24-Outlets PDU NU30005 MNU3EGB0-24S203-2TL5A0A10-S

Geist 24-Outlets PDU NU30005 MNU3EGB0-24S203-2TL5A0A10-S
Price $1,491.90
Manufacturer: Geist
Mfg Number: NU30005
Model: MNU3EGB0-24S203-2TL5A0A10-S
Condition: New
The NU30005 provides IP-based monitoring and outlet control with quick access to real-time outlet-level power metrics and environmental sensor data. Using Visible Light Communication (VLC) technology, NU30005 optically transmits power usage data from its LED display to a handheld device using the Geist Mobile App, presenting comprehensive power usage data down to the phase and circuit levels. With the Geist Upgradeable hot-swap technology, users may easily upgrade PDUs to the latest available technology by replacing the Interchangeable Monitoring Device (IMD) module.
Network (RJ-45) Yes
Product Type PDU
Manufacturer Part Number NU30005
Manufacturer Website Address http://www.vertiv.com/
Manufacturer Vertiv
Product Model MNU3EGB0-24S203-2TL5A0A10-S
Product Name MNU3EGB0-24S203-2TL5A0A10-S 24-Outlets PDU
Brand Name Geist
  • DHCP
  • HTTP
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
Package Contents
  • MNU3EGB0-24S203-2TL5A0A10-S 24-Outlets PDU
  • Vertical Mounting Bracket Kit
Country of Origin United States
Environmentally Friendly Yes
Environmental Certification RoHS
Length 66.3"
Mount Type Rack-mountable
Rack Height 0U
Width 2"
Depth 2.6"
Mounting Orientation Vertical
Input Voltage 120 V AC
Output Voltage 120 V AC
Input Current 20 A
Input Voltage Range 100 V AC - 120 V AC
Power Rating (Watt) 1900 W
Protection Type Overcurrent Protection
Plug/Connector Type NEMA L5-20P
Receptacle Type NEMA 5-20R
PDU Type Switched
Receptacle Detail 24 x NEMA 5-20R
Plug/Connector Detail 1 x NEMA L5-20P
Limited Warranty 5 Year
