Gigabyte (rev. 100) AMD EPYC 7002 DP Server System - 2U 12-Bay R282-Z90

AMD EPYC™ 7002 Series Processor (Rome) The next generation of AMD EPYC has arrived, providing incredible compute, IO and bandwidth capability - designed to meet the huge demand for more compute in big data analytics, HPC and cloud computing. Built on 7nm advanced process technology - the best the industry has to offer, allowing for denser compute capabilities with lower power consumption The world's first 64 core data center CPU, built using Zen 2 high performance cores and AMD's innovative chiplet architecture The world's first mainstream PCIe Gen 4.0 data center CPU with a bandwidth of up to 64GB/s, twice of PCIe Gen 3.0 Embedded security protection to help defend your CPU, applications, and data PCIe Gen 4.0 Ready AMD EPYC Rome is the world's first mainstream data center CPU to support PCIe Gen 4.0, with a bandwidth of 64GB/s, twice that of PCIe Gen 3.0. This doubles the bandwidth available from the CPU to peripheral devices such as graphics cards, storage devices and high speed network cards. GIGABYTE's AMD EPYC 7002 Series server platforms are ready to be used with a new generation of PCIe Gen 4.0 devices such as AMD's Radeon MI50 GPGPU. Higher Memory Speed AMD EPYC's Rome 7002 Series processors feature faster 8 channel DDR4 memory lanes, supporting RDIMM or LRDIMM memory modules with a speed of up to 3200MHz (1 DIMM per channel) More M.2 Storage GIGABYTE's AMD EPYC 7002 Series server platforms feature more M.2 drive capacity for ultra-fast NVMe storage - both onboard M.2 slots and extra capacity via optional riser cards. OCP 3.0 Add-On Card Ready GIGABYTE's AMD EPYC Rome Server Platforms feature an onboard OCP 3.0 mezzanine slot for the next generation of PCI Gen 4.0 add on cards. Compared to previous OCP 2.0 type cards, advantages of this new type include: Easier Serviceability: simply slot in / pull out the card without needing to open the server chassis; tool less design Larger Thermal Envelope: more space for heat sink provides an increased power budget for new & emerging capabilities Max TDP Support GIGABYTE's AMD EPYC server platforms come ready to support the full list of AMD EPYC Rome 7002 Series processors: up to 225W (standard TDP) / 240W (cTDP) Data Security TPM 2.0 Module GIGABYTE's AMD EPYC Server is designed to support Trusted Platform Modules (TPM - discrete cryptographic on-board processors). Design Features for Easy Maintenance GIGABYTE's AMD EPYC 7002 Series server platforms contain many tool less design features for easy installation, maintenance and removal - never worry about forgetting your toolbox or losing a screw again! Tool-less Rail Kits Rail kits attach to the side of the server chassis via clipping mechanism. Tool-less 2.5" & 3.5" Drive Bays Clipping mechanism secures the drive in place. Install or replace a new drive in seconds. Efficient, Reliable Power Supply GIGABYTE's AMD EPYC 7002 Series server are designed to guarantee high conversion efficiency regardless of load. Redundant 80 Plus 'Titanium' or 'Platinum' PSUs, combined with GIGABYTE's precision engineering, translates to super efficient power usage which maximizes the system's power : performance ratio and reduces OPEX for the user.

Total Number of USB Ports	5
Number of USB 3.0 Ports	5
Controller Type	Serial ATA/600
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Product Type	Barebone System
Manufacturer Part Number	R282-Z90
Manufacturer Website Address	http://www.gigabyte.us
Packaged Quantity	1
Manufacturer	GIGABYTE Technology, Inc
Product Model	R282-Z90
Product Name	R282-Z90 (rev. 100) AMD EPYC 7002 DP Server System - 2U 12-Bay
Brand Name	Gigabyte
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	14
Number of 3.5" Bays	12
Maximum Memory Supported	128 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Number of Total Memory Slots	32
Package Contents	R282-Z90 (rev. 100) AMD EPYC 7002 DP Server System - 2U 12-Bay 2 x CPU heatsinks 1 x Rail kit
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	RoHS
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	39.68 lb
Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	17.2"
Depth	28.7"
Input Voltage	120 V AC 230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1200 W
Limited Warranty	1 Year
Processor Supported	EPYC
Processor Socket	Socket SP3
Number of Processors Supported	2
Chipset Manufacturer	AMD
Operating System Supported	Windows Server 2016 Windows Server 2019 Red Hat Enterprise Linux 7.6 x64 Red Hat Enterprise Linux 8.0 x64 SuSE Linux Enterprise Server 12 x64 SuSE Linux Enterprise Server 15 x64 Ubuntu 16.04.6 LTS x64 Ubuntu 18.04.2 LTS x64
