Gigabyte (rev. 1.0) Server Motherboard W480 VISION D

VISION Series motherboards are built for creator pc. It featured with reliable performance, impressive connectivity, expandable on graphics, and ultra-fast storage for creators to deal with heavy design workloads such as video editing and 3D rendering. It's the perfect fit for DIY creators to build their own ideal machine. Intel® Xeon® Processor and ECC Memory Enhanced performance. Reduce crashes. Intel® Xeon® processor enables you to create, test, and deliver solutions faster than ever.Error Correction Code (ECC) powered by Intel® Xeon® processor tests for and corrects errors in your data as it passes in and out of memory to ensure reliability for critical applications. More Speed. More Pixels. More Possibilities. Thunderbolt™ 3 is the single most advanced port available. It uses USB-C connectors and cables but as a single cable solution, creating one compact port that delivers the fastest connection to any dock display or data device. The only cable you need brings the limitless connectivity with you. High-Bandwidth and Low-Latency Access-LayerNetwork Support Dual Intel® Server-Grade LAN With both LAN ports designed, you'll benefit from increased bandwidth for speed, automated load balancing for smoother data flow, and instant failover if anything goes wrong.Adoption of one 2.5G LAN provides up to 2.5 GbE network connectivity, with at least two times faster transfer speeds compared to general 1GbE networking. It is also backward compatible with Multi-Gig (10/100/1000/2500Mbps) RJ-45 Ethernet. Cooling Technology An effective cooling solution is essential for a heavy design workload to get away with slow down, crashes, and unexpected shutdown.Unconventional Heatsinks is designed for better thermal dissipation but also aesthetically appealing to creators. A heat pipe connects a giant curved heatsink and micro cube heatsink that fully cover the VRM area. It ensures the heat can be dissipated more efficiently.In addition, all the M.2 SSD are all covered with ultra efficient dual sided heatsinks, so creators can move big files with un-throttled transfer speed and prolong SSD longevity. PCI Express 4.0 Hardware Design For most prosumers and content creators, high bandwidth storage and high performance graphics card or accelerator cards are critical for their projects. This is especially true for 3D rendering and creating high resolution textures. To support most cutting edge devices, this motherboard uses the groundbreaking PCIe 4.0 hardware design. From PCB, several new IC to device connectors, everything that the PCIe 4.0 signal goes is a completely new generation, to make sure your content creation PC is future proof. PCIe M.2 Faster Speed. More Space. M.2 Drives keep the load times away. Breaking the barriers of SATA limitations. M.2 PCIe SSD gives you X7 faster data transferring experience compared to 2.5" SATA solid state drives. DTS:X® Ultra Immersive sounds to go DTS:X Ultra is capable of delivering consumers a truly premium entertainment experience by completely surrounding the listener and expanding the sound stage to create a more immersive environment. Supports channel-based, scene based, and object-based audio. Also, it takes movies, music, and interactive gaming experiences to an exciting new level.

Audio Channels	7.1
S/PDIF	Yes
HDMI	Yes
Number of Network (RJ-45) Ports	2
DisplayPort	Yes
Total Number of USB Ports	8
Number of USB 2.0 Ports	2
Number of Thunderbolt 3 Ports	2
Number of USB 3.2 Ports	6
Product Type	Server Motherboard
Manufacturer Part Number	W480 VISION D
Manufacturer Website Address	http://www.gigabyte.us
Manufacturer	GIGABYTE Technology, Inc
Product Model	W480 VISION D
Product Name	W480 VISION D (rev. 1.0) Server Motherboard
Product Series	VISION
Brand Name	Gigabyte
Number of PCI Express x1 Slots	1
Number of Total Expansion Slots	4
Number of PCI Express x16 Slots	3
Total Number of PCI Express Slots	4
Maximum Memory Supported	128 GB
Memory Technology	DDR4 SDRAM
Number of Memory Slots	4
Memory Form Factor	DIMM UDIMM
Memory Speed Supported	4266 MHz 4133 MHz 4000 MHz 3866 MHz 3800 MHz 3733 MHz 3666 MHz 3600 MHz 3466 MHz 3400 MHz 3333 MHz 3300 MHz 3200 MHz 3000 MHz 2933 MHz 2800 MHz 2666 MHz 2400 MHz 2133 MHz 4400 MHz 4300 MHz
Intel Optane Memory Ready	Yes
Bluetooth	Yes
Gigabit Ethernet	Yes
Wireless LAN	Yes
Wireless LAN Standard	IEEE 802.11 a/b/g/n/ac/ax
2.5Gigabit Ethernet	Yes
Form Factor	ATX
Width	12"
Depth	9.6"
Processor Supported	Xeon W Celeron Core i3 Core i5 Core i7 Core i9 Pentium Gold
Total Processor Supported	1
Processor Socket	Socket LGA-1200
Chipset Manufacturer	Intel
Chipset Model	W480
Multi GPU Supported	CrossFire
Onboard Video	CPU Dependent Video
RAID Levels	0 1 5 10
Controller Type	Serial ATA/600
RAID Supported	Yes
Number of SATA Interfaces	6
Total Number of Onboard USB Ports	7
Number of Onboard USB 2.0 Ports	4
Number of M.2 Interfaces	3
Number of Onboard USB 3.2 Ports	3
