Hanwha Techwin TMC-GSFP Transceiver/Media Converter TMC-GSFPPOEM

Hanwha Techwin TMC-GSFP Transceiver/Media Converter TMC-GSFPPOEM
Price $754.60
Manufacturer: Hanwha Techwin
Mfg Number: TMC-GSFPPOEM
SKU:
Condition: New
UPC: 849688012079
Accessories
Description
The TMC-GSFP electrical-to-optical Ethernet media converters accept a 10/100 or 1000 Mbps electrical input and converts to a 100 or 1000 Mbps optical output (selected by a dip switch) and the 100/1000 Mbps optical input back to the 10/100/1000 Mbps electrical output. "Auto-Negotiating" is supported on the copper interface side. These devices use either one or two optical fibers, depending upon the selection of sold-separately SFP optical module. A PoE model, the TMC-GSFPPOEM meets the IEEE802.3at standard and provides 30 watts of PoE+ power. The series consists of small size single channel models, TMC-GSFPM & TMC-GSFPPOEM, and a standard size, single-channel model, TMC-GSFP. The standard size unit may be directly plugged into the SBP-C14 / SBP-C03 Rack or operated as a standalone module. The small size unit operates as standalone modules only.
Specifications
Product Type Transceiver/Media Converter
Product Series TMC-GSFP
Brand Name Hanwha Techwin
Manufacturer Hanwha Group
Product Name TMC-GSFP Transceiver/Media Converter
Manufacturer Part Number TMC-GSFPPOEM
Manufacturer Website Address http://www.hanwha.com
Environmentally Friendly Yes
Environmental Certification RoHS WEEE
Ethernet Technology Gigabit Ethernet
Network Technology 10/100/1000Base-TX 1000Base-FX
Number of Total Expansion Slots 1
Number of SFP Slots 1
Expansion Slot Type SFP (mini-GBIC)
Number of Network (RJ-45) Ports 1
Network (RJ-45) Yes
Total Number of Ports 1
Media Type Supported Twisted Pair Optical Fiber
Fiber Mode Supported Single-mode Multi-mode
Maximum Distance Supported 74.56 Mile
Height 1.1"
Width 3.3"
Depth 2.5"
Form Factor Standalone DIN Rail Mountable
Power Source DC
