IO Crest 2 Port SATA III PCI-e 3.0 x1 Controller Card (Jmicro Chipset) SI-PEX40148

The IO Crest 2 Port SATA III PCI-e 3.0 x1 card ( SI-PEX40148 ) is the easiest way to update any computer with SATA ports with a PCI-e x1 slot or larger. Once installed this host card will add SATA ports with two independent channels. This allows support of two SATA devices at speeds of up to 6Gb/s whether it is a SATA hard drive or SATA device. Using the JMB582 chipset, the SI-PEX40148 can provide a maxium sequencial Read / Write Speed of 850 MB/s to 2 SATA 6Gb/s ports. For the storage solution based on data transfer of multiple hard drives, the newly added FIS-based switching design can overcome the bottlenecks created by operating multiple SATA storage devices simultaneously.

Total Number of SATA Ports	2
Number of SATA Ports (Internal)	2
Product Type	SATA Controller
Manufacturer Part Number	SI-PEX40148
Manufacturer Website Address	http://www.syba.com
Packaged Quantity	1
Manufacturer	SYBA Multimedia, Inc
Product Name	2 Port SATA III PCI-e 3.0 x1 Controller Card (Jmicro Chipset)
Brand Name	IO Crest
Package Contents	2 Port SATA III PCI-e 3.0 x1 Controller Card (Jmicro Chipset) 1 x Low Profile Bracket 1 x SATA Cable 1 x Manual 1 x Driver CD
Platform Supported	PC Linux Mac
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	WEEE
Form Factor	Plug-in Card
Host Interface	PCI Express 3.0 x1
Controller Type	Serial ATA/600
