KanexPro 4K UHD 1x16 HDMI Distribution Amplifier w/ HDCP2.2 HDSP164K

The KanexPro 1x16 HDMI Distribution Amplifier is an installer-friendly, lightweight HDMI splitter that distributes one HDMI input into sixteen identical outputs supporting uncompressed 4K UHD resolutions. The conforming outputs also have the ability of buffering and amplifying all the HDMI signals. It can achieve long distance transmission of HDMI signals up to 50 feet (15 meters) or can be combined with our HDBaseT™ Extenders to route distances up to 330 feet (100 meters). It accepts computer resolutions up to WUXGA (1920x1200 @ 60Hz), including HDTV 1080p/60 and 4K/60 with built-in EDID management. The 1x16 DA fully conforms to the latest High Speed HDMI 2.0 specifications with HDCP 2.2. This professional HDMI splitter is optimized for routing HDMI video and embedded multi-channel digital audio to multiple display environments such as digital signage, hospitality markets, airports, shopping malls and medical imaging. Features: Distribute 4K HDMI video and audio signals to up to sixteen 4K displays Supports full HD 1080p (1920 x 1080@60Hz) & 4K UHD Conforms to High Speed HDMI 2.0 specifications HDMI Bandwidth up to 18 Gbps Supports Dolby Digital, DTS-HD and Dolby True HD audio HDCP 2.2 compliant Built-in Smart EDID Control Front-panel LED's for input/ output signal presence 5VDC external power supply included

Number of HDMI Inputs	1
Number of HDMI Outputs	16
HDMI In	Yes
HDMI Out	Yes
Product Type	Audio/Video Distribution Amplifier
Manufacturer Part Number	HDSP164K
Manufacturer Website Address	http://www.kanexpro.com
Manufacturer	KanexPro
Product Name	4K UHD 1x16 HDMI Distribution Amplifier w/ HDCP2.2
Brand Name	KanexPro
Package Contents	4K UHD 1x16 HDMI Distribution Amplifier w/ HDCP2.2 External Power Supply
Weight (Approximate)	2.20 lb
Height	1.8"
Width	4.5"
Depth	10.6"
Product Material	Metal
Input Voltage	12 V DC
Maximum Video Resolution	3840
