Kingston RAM Module KSM48R40BS8-16MD

Kingston's KSM48R40BS8-16MD is a 2G x 80-bit (16GB) DDR5-4800 CL40 SDRAM (Synchronous DRAM), 1Rx8, ECC, memory module, based on ten 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:

Product Type	RAM Module
Manufacturer Part Number	KSM48R40BS8-16MD
Manufacturer Website Address	http://www.kingston.com
Manufacturer	Kingston Technology Company
Product Name	RAM Module
Brand Name	Kingston
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Number of Pins	288-pin
Thickness	68.9 mil
Form Factor	DIMM
Length	1.2"
Width	5.3"
CAS Latency	CL40
Device Supported	Computer
Error Checking	ECC
Number of Modules	1 x 16GB
Signal Processing	Registered
Memory Size	16 GB
Memory Technology	DDR5 SDRAM
Memory Standard	DDR5-4800/PC5-38400
Memory Voltage	1.10 V
Memory Rank	Single-rank
