Kramer 4x8 4K60 4:2:0 Matrix Switcher 20-04800130 VS-48UHD

Kramer 4x8 4K60 4:2:0 Matrix Switcher 20-04800130 VS-48UHD
$3108.00
Manufacturer: Kramer
Mfg Number: 20-04800130
SKU:
Model: VS-48UHD
Condition: New
Accessories
Description
VS-48UHD is a high-quality 4x8 matrix switcher for [email protected] (4:2:0) HDMI signals and embedded audio. It reclocks and equalizes the signals and can route any one of four HDMI, HDCP-compliant sources (selectable) to any or all outputs simultaneously. VS-48UHD offers a flexible audio scheme where any HDMI digital audio input can be routed to any HDMI digital audio output in addition to ARC support to produce an equivalent 12x10 audio matrix. Max. Data Rate - 8.91Gbps data rate (2.97Gbps per graphics channel). Max. Resolution - [email protected] (4:2:0). Independent 12x10 Audio Matrix - With 4 embedded digital inputs + 8 ARC inputs and 8 digital outputs + 2 ARC outputs. Kramer Step-In Over HDMI Technology. HDMI, HDCP and DVI Compliance. Selectable HDCP Off per Input. Memory Locations - 12 presets for quick access to common configurations. Advanced EDID Management per Input. Active Source & Acceptor Detection. Automatic Input Selection - Based on priority selection or last connected input. Firmware Upgrade - Via mini USB, Ethernet or the RS-232 port. HDMI Support - Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels. Kramer reKlocking™ and Equalization Technology - Rebuilds the digital signal to travel longer distances. Embedded Pattern Generator - With selectable patterns. Lock Button - To prevent tampering. Kramer Protocol 3000 Support. Control Options - RS-232 serial commands transmitted by a PC, touch screen system or other serial controller, Ethernet port via LAN, embedded Web pages via LAN for configuration and control. Size - Standard 19" (1U). Rack "ears" included. APPLICATIONS Control rooms with multiple displays Presentation and multimedia applications Systems that require automatic HDMI routing
Specifications
Product Type Video Switchbox
Brand Name Kramer
Manufacturer Kramer Electronics LTD
Product Model VS-48UHD
Product Name VS-48UHD 4x8 4K60 4:2:0 Matrix Switcher
Manufacturer Website Address http://www.kramerelectronics.com
Graphics Modes 4K
Number of USB Ports 2
Number of HDMI Inputs 4
Number of HDMI Outputs 8
HDMI In Yes
HDMI Out Yes
Connectivity (RJ-45) Yes
Number of Connectivity (RJ-45) Ports 1
Media Type Supported Twisted Pair
Number of Displays Supported 8
Number of Input Devices Supported 4
Connectivity Technology Cable
Device Supported Display
Height 1.7"
Width 17.2"
Depth 9.3"
Form Factor Rack-mountable
Weight (Approximate) 5.29 lb
