Kramer 4x4 HDCP Compliant DVI Matrix Switcher VS-44HDCP

+ Wishlist

Manufacturer: Kramer
Mfg Number: VS-44HDCP
SKU:
Condition: New

Accessories

View All Products in Video Electronics

Description

The VS-44HDCP is a high-quality, HDCP compliant 4x4 DVI matrix switcher. It reclocks and equalizes the signals and can route any of the four DVI/HDMI (over DVI-I connectors) inputs to any of the four DVI/HDMI outputs simultaneously. Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel). HDCP Compliant. HDTV Compatible. HDMI Support - HDMI support for Deep Color, x.v.Color™, Dolby® TrueHD, Dolby Digital Plus, DTS?HD®, and linear PCM 7.1 surround sound. Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances. EDID Capture - Copies and stores the EDID from a display device. Front Panel Control Lockout. Output Disconnect - For each output. Memory Locations - Stores multiple switches as presets to be recalled and executed when needed. Communication Support - Support for Kramer Protocol 2000 and Protocol 3000. Flexible Control Options - Front panel, IR remote, RS?232 (K?Router Plus™ Windows®?based software is included), Ethernet (Windows®?based Ethernet Configuration Manager & Virtual Serial Port Manager is included). Worldwide Power Supply - 100?240V AC. Size - Standard 19" (1U).

Specifications

Product Type	Audio/Video Switchbox
Brand Name	Kramer
Manufacturer	Kramer Electronics LTD
Product Model	VS-44HDCP
Product Name	4x4 HDCP Compliant DVI Matrix Switcher
Manufacturer Part Number	VS-44HDCP
Manufacturer Website Address	http://www.kramerelectronics.com
Graphics Modes	UXGA
Scan Format	1080p
Maximum Video Resolution	1600 x 1200
Number of DVI Outputs	4
DVI In	Yes
DVI Out	Yes
Number of DVI Inputs	4
Connectivity (RJ-45)	Yes
Number of Connectivity (RJ-45) Ports	1
Media Type Supported	Twisted Pair
Number of Displays Supported	4
Number of Input Devices Supported	4
Connectivity Technology	Cable
Device Supported	DisplayComputerBlu-ray Disc PlayerTV
Height	1.8"
Width	19"
Depth	9.4"
Form Factor	Rack-mountable
Weight (Approximate)	3.70 lb
Package Contents	4x4 HDCP Compliant DVI Matrix Switcher Power Cord IR Transmitter Rack "Ears"
Limited Warranty	7 Year
