The VM-212DT is
[email protected] (4:2:0) HDMI & extended-reach HDBaseT DA for HDMI and HDBaseT signals. It reclocks and equalizes the signal and distributes it to two identical HDBaseT outputs and a looping HDMI output. It supports resolutions up to
[email protected] (4:2:0). This product offers the versatility of control options and audio de-embedding. Resolution Support - Up to
[email protected] (4:2:0). Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel). HDTV Compatible. HDCP Compliant - Works with sources that support HDCP repeater mode. HDMI Support - Deep Color, x.v.Color™ and 3D. Automatic Live Input Detection - Based on video clock presence. Automatic Analog Audio Detection & De-embedding. Looping HDMI Output - Allow monitoring and cascading to additional DAs. I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems. System Range - Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC-UNIKAT cables. Data Equalization and Reclocking. Support for Digital Audio Formats. Lockable EDID and Default EDID - For fast and efficient connection of the unit. Support for EDID Designer.
