Lenovo ThinkSystem 2.5" 5300 960GB Entry SATA 6Gb Hot Swap SSD SED 4XB7A38141

The ThinkSystem 5300 Entry SATA 6Gb solid-state drives (SSDs) are high-performance self-encrypting drives (SEDs) that adhere to the Trusted Computing Group Enterprise Security Subsystem Class cryptographic standard (TCG Enterprise SSC or eSSC). They use Micron NAND flash memory technology with a SATA 6Gbps interface to provide an affordable solution for secure read-intensive workloads.

Drive Interface	SATA
Drive Interface Standard	SATA/600
Maximum Read Transfer Rate	540 MB/s
Maximum Write Transfer Rate	520 MB/s
Random 4KB Read	95000IOPS
Random 4KB Write	35000IOPS
Endurance (DWPD)	1.5
Endurance (TBW)	2628 TB
Endurance Type	Read Intensive
Product Type	Solid State Drive
Manufacturer Part Number	4XB7A38141
Manufacturer Website Address	http://www.lenovo.com/us/en/
Manufacturer	Lenovo Group Limited
Product Name	ThinkSystem 2.5" 5300 960GB Entry SATA 6Gb Hot Swap SSD SED
Product Series	5300
Brand Name	Lenovo
Compatibility	Lenovo ThinKSystem Servers: SR630 (7X01/7X02) SR650 (7X05/7X06) SR635 (7Y98/7Y99) SR655 (7Y00/7Z01) SD530 (7X21)
Device Supported	Server
Wireless LAN	No
Hot Swappable	Yes
Weight (Approximate)	2.47 oz
Drive Type	Internal
Form Factor	2.5"
Height	0.3"
Width	2.8"
Depth	3.9"
Storage Capacity	960 GB
Encryption Standard	256-bit
