Middle Atlantic Products 24-Outlets PDU PD-DC-300-24V

Optimize any installation with the industry-leading power capacity of the fixed voltage, DC Power Distribution line. These solutions not only remove messy, space-consuming, unreliable wall warts and other power clutter from the design, but also provide maximum power to support a multitude of 12V devices. The 300W unit provides high current capacity to an extensive number of 12V outputs, maximizing the same voltage in the single unit. The multi-mount design can be installed in an available 1RU space or at the back or side of the rack for zero-U mounting, providing ultimate installation flexibility. Promoting enhanced design of system power demands, while still providing a seamless install experience, the 300W DC Power Distribution line is innovatively engineered for multiple applications spanning markets from North America to Europe.

Product Type	PDU
Manufacturer Part Number	PD-DC-300-24V
Manufacturer Website Address	http://www.legrand.us
Manufacturer	Legrand Group
Product Model	PD-DC-300-24V
Product Name	PD-DC-300-24V 24-Outlets PDU
Brand Name	Middle Atlantic
Package Contents	PD-DC-300-24V 24-Outlets PDU Flexible Mounting Hardware Color-coded Screw Terminal Connectors to Connect Devices 1 x 6ft IEC Power Cord
Environmentally Friendly	Yes
Environmental Certification	EU RoHS RoHS
Mount Type	Rack-mountable
Rack Height	0U/1U
Height	1.8"
Width	19"
Depth	7.3"
Input Voltage	120 V AC 230 V AC
Output Voltage	24 V DC
Input Current	12.50 A
Input Voltage Range	120 V AC - 230 V AC
Power Rating (Watt)	300 W
Protection Type	Surge Protection Overload Protection
Plug/Connector Type	NEMA 5-15P
Receptacle Type	Screw Terminal
Receptacle Detail	24 x Screw Terminal
Plug/Connector Detail	1 x NEMA 5-15P
Limited Warranty	3 Year
