Middle Atlantic Products SNE Series Rack SNE24D-4542-P1

The SNE Series Digital is configured for digital (IP based) security systems consisting of high-density cabling, network equipment, and servers. Optional Tool-Free Lever Lock™ system accommodates small devices including encoders, power supplies, and Access Control Systems. Fully configured Security Network Enclosure with passive ventilation for data centers o 70% open area vented front door o Pair of split flush mount locking side panels o 2 pair of adjustable cage-nut rackrail (including 6mm hardware) o Lever Lock™ compatible (accepts all Lever Lock™ vertical 21" accessories) o 24" width o 42" overall depth o 45 rackspace o 100 6mm cage-nuts/rack screws included SNE Series Digital with passive cooling (front to rear) 70% open area split rear door Solid top with brush cable pass-through Lever Lock™ compatible (accepts all 21" vertical accessories) Configured for passive front-to-back cooling Includes 70% open front door and 70% open area split rear door Includes solid top with brush cable pass-through Includes pair of split flush mount locking side panels UTL/ETL listed and seismic certified Includes 2 pair of adjustable cage-nut rackrail Includes 100 6mm cage nuts and rack screws Includes 4 leveling feet Includes 4 casters

Product Type	Rack Cabinet
Product Series	SNE
Brand Name	Middle Atlantic
Manufacturer	Legrand Group
Product Model	SNE24D-4542-P1
Product Name	SNE Series Rack, SNE24D-4542-P1
Manufacturer Part Number	SNE24D-4542-P1
Manufacturer Website Address	http://www.legrand.us
Environmentally Friendly	Yes
Environmental Certification	RoHSLEEDECO PASSPORTGREENGUARD Gold
Assembly Required	No
Static/Stationary Weight Capacity	12000 lb
Rack Depth	38.48"
Height	84.8"
Width	24"
Depth	43.2"
Color	Black Powder Coat
Rack Width	19"
Rack Height	45U
Form Factor	Floor Standing
Material	SteelSteel Rail
Application/Usage	ServerLAN SwitchPatch Panel
Limited Warranty	Lifetime
