Monoprice IEEE 1284 , DB25M/CN36M , 18PR. - 10ft 376

Monoprice IEEE 1284 , DB25M/CN36M , 18PR. - 10ft 376
Price $11.69
Manufacturer: Monoprice
Mfg Number: 376
Condition: New
UPC: 844660003762
IEEE 1284 , DB25M/CN36M , 18PR. - 10ft Before the advent of printers with USB connections, the dominant standard was IEEE 1284, aka the "parallel printer interface". If you have a computer and printer with this interface, you can depend on Monoprice to stock the cables you will need to connect them!This parallel printer cable provides the most common printer connection with a DB25 male connector on one end, to connect to the computer's parallel port, and a Centronics CN36 male connector on the other end, to connect to the printer's parallel port.The 18 conductors in this cable consist of 18 tightly woven pairs of wires, with one conductor in each providing the signal and the second providing a dedicated ground return (except for the 18th pair, which is used device detection). The connector heads are molded onto the cable and the DB25 end has thumbscrews for securing the connector to the computer, while the CN36 end has metal clip receptacles for securing it to the printer.
Product TypeData Transfer Cable
Brand NameMonoprice
ManufacturerMonoprice, Inc
Product NameIEEE 1284 , DB25M/CN36M , 18PR. - 10ft
Manufacturer Part Number376
Manufacturer Website Addresshttp://www.monoprice.com
Connector on First End1 x 25-pin DB-25 Male IEEE 1284 Parallel
Connector on Second End1 x 36-pin CN36 Male Parallel
Cable TypeParallel
Device SupportedPrinter
Cable Length10 ft
Limited WarrantyLifetime
