MSI MAG Desktop Motherboard B460TORPEDO B460 TORPEDO

MAG B460 TORPEDO features high-bandwidth and low-latency 2.5 Gigabit LAN for demanding creators and power users, provides incredible data transfer speed faster than ever before. MSI LAN Manager automatically classifies and prioritizes the latency-sensitive for your applications, giving you the best online experience with low latency.

Audio Channels	7.1
S/PDIF	Yes
HDMI	Yes
Number of Network (RJ-45) Ports	1
DisplayPort	Yes
Total Number of USB Ports	6
Number of USB 2.0 Ports	2
Number of USB 3.2 Ports	4
Product Type	Desktop Motherboard
Manufacturer Part Number	B460TORPEDO
Manufacturer Website Address	http://www.msi.com
Manufacturer	MSI
Product Model	B460 TORPEDO
Product Name	MAG B460 TORPEDO Desktop Motherboard
Product Line	MAG
Brand Name	MSI
Number of PCI Express x1 Slots	2
Number of Total Expansion Slots	4
Number of PCI Express x16 Slots	2
Total Number of PCI Express Slots	4
Maximum Memory Supported	128 GB
Memory Technology	DDR4 SDRAM
Number of Memory Slots	4
Memory Form Factor	DIMM UDIMM
Memory Speed Supported	2666 MHz 2933 MHz
Intel Optane Memory Ready	Yes
Package Contents	MAG B460 TORPEDO Desktop Motherboard User Manual Quick Installation Guide MSI Case Badge 2 x SATA Cables Product Registration Card MSI Product Catalog Driver DVD
Country of Origin	China
2.5Gigabit Ethernet	Yes
Form Factor	ATX
Width	12"
Depth	9.6"
Processor Supported	Pentium Gold Celeron Core i5 Core i7 Core i9
Total Processor Supported	1
Processor Socket	Socket LGA-1200
Chipset Manufacturer	Intel
Chipset Model	B460
Onboard Video	CPU Dependent Video
Limited Warranty	3 Year
RAID Levels	0 1 5 10
Controller Type	Serial ATA/600
RAID Supported	Yes
Intel RST	Yes
Number of SATA Interfaces	6
Total Number of Onboard USB Ports	7
Number of Onboard USB 2.0 Ports	4
Number of M.2 Interfaces	2
Number of Onboard USB 3.2 Ports	3
