Panorama Antennas MiMo Wifi Adhesive Mount Antennna RAYM2-24-58

The RAYM2-24-58 range has been designed as a cost effective solution for telematics / asset tracking applications MiMo WIFI. Supports 2x2 MiMo WiFi 2.4/5.0GHz Mount on or under dashboard on on windshield Integrated double shielded low loss cables compliant to UN118.01 The compact, robust low-profile housing contains two elements providing MiMo WiFi 2.4/5.0GHz coverage. The antenna can be fitted on or under a vehicle dashboard or on a windshield using the supplied acrylic adhesive sealing pad. Supplied with integrated 3m (10') cables which are compliant with UN ECE 118.01 and fitted with Rev Pol SMA Plug connectors, the antenna will offer plug and play connectivity with many different devices.

Connector Type	RP-SMA
Product Type	Antenna
Manufacturer Part Number	RAYM2-24-58
Manufacturer Website Address	http://www.panorama-antennas.com
Manufacturer	Panorama Antennas Ltd
Product Model	RAYM2-24-58
Product Name	RAYM2-24-58 MiMo Wifi Adhesive Mount Antennna
Brand Name	Panorama Antennas
Application/Usage	Vehicle
Package Contents	RAYM2-24-58 MiMo Wifi Adhesive Mount Antennna 3m (10') Cables
Environmentally Friendly	Yes
Environmental Certification	ISO 14001 WEEE REACH RoHS 3
Weight (Approximate)	11.64 oz
Form Factor	Adhesive/Dash/Glass Mount
Height	0.59"
Width	5.16"
Product Color	Black
Directivity	Omni-directional
Frequency Band Type	UHF SHF
Operating Frequency Range	2.4 GHz to 5 GHz
Antenna Gain (Isotropic)	2 dBi
