Promise VTrak Drive Enclosure J5600SDQS12 J5600sD

Affordable Enterprise-Level Storage The VTrak J5000 Series delivers an affordable high performance SAS solution with advanced enterprise level reliability and functionality. The four external 12 Gb/s SAS ports per I/O module provide the connectivity for large capacity solutions requiring multiple cascaded JBODs, and high bandwidth solutions requiring speed. It features fully redundant I/O modules, power supplies and cooling units, combined with a cable-less system design, providing exceptional data availability even during component failures for the enterprise environment. Supports Hybrid HDD/SSD Arrays Fully backward compatible with 6 Gb/s SAS/SATA devices, users have the ability to deploy 3 Gb/s, 6 Gb/s, and 12 Gb/s SAS/SATA HDDs and SSDs in the J5000 Series. Efficient power supplies provide up to 90% power efficiency, which improves TCO by conserving power, reducing heat output, and improving cooling costs. The internal 12 Gb/s SAS expander-based architecture also allows for transparent access to each drive, enabling full utilization of the power management features built into modern hard drives. Increased Performance To Optimize Datacenters The VTrak J5000 Series moves data at incredible speeds, allowing you to optimize your datacenter. Administrators can deploy with the fastest SAS bus speed with 12 Gb/s HDDs or SSDs. These systems are fully backward compatible with 6 Gb/s SAS/SATA drives, yet are still able to optimize the full port bandwidth of 12 Gb/s to the host. Flash arrays allow you to optimize speed for key enterprise apps that require utmost performance. The internal 12 Gb/s SAS expander-based architecture allows for data to transfer faster with greater redundancy protection.

Host Interface	12Gb/s SAS
Non-RAID Mode	JBOD
Product Type	Drive Enclosure
Manufacturer Part Number	J5600SDQS12
Manufacturer Website Address	http://www.promise.com
Manufacturer	Promise Technology
Product Model	J5600sD
Product Name	VTrak J5600sD Drive Enclosure
Product Line	VTrak
Product Series	J5000
Brand Name	Promise
Number of Total Expansion Bays	16
Number of 3.5" Bays	16
Country of Origin	Taiwan
Environmentally Friendly	Yes
Environmental Certification	WEEE RoHS
Wireless LAN	No
Weight (Approximate)	84.44 lb
Form Factor	Rack-mountable
Rack Height	3U
Height	5.2"
Width	17.6"
Depth	20"
Total Hard Drive Capacity Installed	192 TB
Number of Hard Drives Supported	16
Number of Hard Drives Installed	16
Limited Warranty	3 Year
