Sans Digital EliteSTOR DAS Array KT-ES108X6+B ES108X6+B

The EliteSTOR ES108X6+B is a 1U SAS 6G JBOD rackmount for high capacity storage solution, with 2.5" form factor. Utilizing the latest 6G SAS expander technology, the ES108X6+B provides over 24Gb/s or 2400MB/s of bandwidth to fulfill the most demanding application. The ES108X6+B supports 2.5" SATA or SAS 6Gb/s hard drives or SSD and is backward compatible to 3Gb/s SAS & SATA hard drives. By utilizing the latest SAS expander technology, the ES108X6+B supports up to 8 * 2.5" SAS or SATA drives using only one mini-SAS cable. A built-in SAS expansion port enables the system to connect up to 5 units or 40 HDD drives daisy-chained together. With a high performance RAID controller card such as Areca ARC-1882X or LSI 9285-8E, the ES108X6+B is capable of delivering over 1700MB/s in read and 1500MB/s write performance, doubling the existing 3G SAS expander bandwidth. System status information is provided by the LED, including hard drives, power supply and cooling fan status. All necessary hardware comes standard including mini-SAS cable, hard drives tray modules and built-in mounting rail. The ES108X6+B is an ideal storage expansion solution for servers or high performance video editing workstations.

Product Type	DAS Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	ES108X6+B
Product Name	EliteSTOR ES108X6+B DAS Array
Product Line	EliteSTOR
Manufacturer Part Number	KT-ES108X6+B
Manufacturer Website Address	http://www.sansdigital.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	EliteSTOR ES108X6+B DAS Array Mini-SAS Cable Tray Modules Mounting Rail Cooling Fan
Number of Total Expansion Bays	8
Number of 3.5" Bays	No
Number of 5.25" Bays	No
Number of 2.5" Bays	8
Number of 2.5"/3.5" Bays	No
Total Hard Drive Capacity Supported	8 TB
Total Solid State Drive Capacity Supported	8 TB
Number of Hard Drives Supported	8
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	8
Number of Solid State Drive Installed	No
Height	1.8"
Width	19"
Depth	23"
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	20 lb
RAID Levels	JBOD
Controller Type	Serial ATA/6006Gb/s SAS
Limited Warranty	3 Year
Host Interface	Mini-SAS
