Sans Digital EliteSTOR DAS Array KT-ES316X12HP ES316X12HP

The EliteSTOR ES316X12HP is a complete 3U 12G SAS RAID solution for performance hungry RAID storage solution. Utilizing the latest 12G SAS expander technology, the ES316X12HP provides up to 48Gb/s or 4800MB/s of data bandwidth to fulfill the most demanding application. The ES316X12HP supports SATA or SAS 12Gb/s hard drives or SSD and is backward compatible to 6Gb/s SAS & SATA hard drives. By utilizing the latest SAS expander technology, the ES316X12HP supports up to 16 SAS or SATA drives using only one HD mini-SAS (SFF-8644) cable. A built-in SAS expansion port enables the system to connect up to 256 drives drives daisy-chained together. The system comes with a high performance RAID controller card, and the ES316X12HP is capable of delivering over in 3,000MB/s read and write performance, doubling the existing 6G SAS expander bandwidth. Dedicated dual-core RAID engines provides RAID 0, 1, 3, 5, 6, 10, 50, 60 support with enterprises features and performances. System status information is provided by the LED, including hard drives, power supply and cooling fan status, as well as RAID controller's event log and e-mail notification system. All necessary hardware comes standard including RAID controller card, mini-SAS cable, hard drives tray modules and built-in mounting rail. The ES316X12HP is an ideal storage expansion solution for servers or high performance video editing workstations. Support Windows (Vista or up, Server 2003 or up), Apple (OS X 10.4 or up), Linux and BSD. VMware ESX and Microsoft Hyper-V is also supported.

Product Type	DAS Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	ES316X12HP
Product Name	EliteSTOR ES316X12HP DAS Array
Product Line	EliteSTOR
Manufacturer Part Number	KT-ES316X12HP
Manufacturer Website Address	http://www.sansdigital.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	EliteSTOR ES316X12HP DAS Array 12G PCIe 3.0 RAID Controller Bracket HD Mini-SAS Cable Cooling Fan Tray Modules Build-in Mounting Rail
Number of Total Expansion Bays	16
Number of 3.5" Bays	16
Total Hard Drive Capacity Supported	64 TB
Number of Hard Drives Supported	16
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	16
Number of Solid State Drive Installed	No
Height	5.3"
Width	19"
Depth	23"
Rack Height	3U
Form Factor	Rack-mountable
Weight (Approximate)	46 lb
RAID Levels	JBOD00011E1010+033+0550660
Controller Type	12Gb/s SASSerial ATA/600
Limited Warranty	3 Year
Host Interface	Mini-SAS
