Sans Digital MobileSTOR - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Silver) KT-MS12X6+ MS12X6+

The MobileSTOR MS12X6+ series is a 12 bay mini-SAS SAS expander tower comprised of the same engines as the AccuSTOR / EliteSTOR enterprise level rackmount storage. Utilizing the same engine structure as the enterprise level rackmounts, the MobileSTOR utilize SAS expander technology, and provides up to 24 Gb/s or 2400MB/s of data bandwidth to fulfill the most demanding application. The MS12X6+ supports both SATA or SAS 6Gb/s solid state drives and hard drives and is backward compatible to 3Gbps SAS & SATA SSD and HDDs. By utilizing the latest SAS expander technology, the MS12X6+ supports up to 12 SAS or SATA drives using only one mini-SAS cable. A built-in SAS expansion port enables the system to connect up to 5 units or 40 HDD drives daisy-chained together. With a high performance RAID controller card such as Areca, ATTO, Highpoint and LSI 6G RAID controller, the MS12X6+ is capable of delivering over 1500MB/s in read/write performance with RAID controller, doubling the existing 3G SAS expander bandwidth. Drives status information is provided by the LED. All necessary hardware comes standard including mini-SAS cable, hot-swappable cooling fan, and hard drives tray modules. The MS12X6+ is an ideal storage expansion solution for servers or high performance video editing workstations.

Product Type	DAS Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	MS12X6+
Product Name	MobileSTOR MS12X6+ - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Silver)
Product Line	MobileSTOR
Manufacturer Part Number	KT-MS12X6+
Manufacturer Website Address	http://www.sansdigital.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	MobileSTOR MS12X6+ - 12 Bay SATA/SAS to 6G SAS Expander JBOD Enclosure (Silver) 12 x Removable Tray Modules 1 x Power Cord 1 x Mini-SAS Cable 1 x Quick Installation Manual & CD
RAID Supported	Yes
Controller Type	6Gb/s SASSerial ATA/600
Number of Total Expansion Bays	12
Number of 3.5" Bays	12
Number of 5.25" Bays	No
Number of 2.5" Bays	No
Number of 2.5"/3.5" Bays	No
Total Hard Drive Capacity Supported	48 TB
Total Solid State Drive Capacity Supported	48 TB
Number of Hard Drives Supported	12
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	12
Number of Solid State Drive Installed	No
Height	15.5"
Width	8"
Depth	13"
Form Factor	Tower
Weight (Approximate)	28 lb
Limited Warranty	1 Year
Host Interface	Mini-SAS
