Sans Digital AccuRAID SAN Array ST-SAN-AR424I AR424I

The AccuRAID AR424I is a 4U 24-bay quad channel (4x GbE) iSCSI to SAS/SATA RAID subsystem with redundant controller upgradeable option. With built-in 4x 1Gb Ethernet ports supporting independent access, fail-over or load-balancing (802.3ad port trunking, LACP), AR424I is capable of composing a high performance SAN environment with a fraction of the cost of Fibre Channel RAID storage systems. Built-in redundant controller ready backplane allows non-destructive redundancy controller upgrade path without purchasing a brand new hardware. Supporting RAID 0, 1, 1+0, 3, 5, 6, 30, 50, 60 and JBOD, with global or dedicated hot spare disks, multiple hard drive failure could be protected without downtime or data loss. The built-in powerful 64-bit RAID processor provides high performance through-put. The built-in Snapshot feature provides point-in-time copy of saved data without relying on the host software. Management is available via Web and Secure Web (HTTPS), SSH telnet or serial console, with built-in event notification via e-mail or SNMP trap. Redundant power supplies, cooling fans and controllers are part of the modularized design to allow redundancy as well as off-self spare parts to eliminate downtime. To increase the return of investment, AR424I supports both SAS and SATA drives, and could be expanded by adding up to 3 additional SAS/SATA JBOD units (Total storage 96 bays or 288TB). Intended to provide storage solution for IT and vitalization server computing with VMware vSphere or, Microsoft Hyper-V or Citrix with SCSI-3 persistent target support, the AR424I is a perfect solution for Storage Area Network needs in IT and other applications.

Product Type	SAN Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	AR424I
Product Name	AccuRAID AR424I SAN Array
Product Line	AccuRAID
Manufacturer Part Number	ST-SAN-AR424I
Manufacturer Website Address	http://www.sansdigital.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	AccuRAID AR424I SAN Array 1 x Set of Rail Bracket 2 x Power Cords 1 x Serial Cable 1 x Ethernet Cable Hard Drive Mounting Screws and Trays 1 x CD and User Guide
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Bays	24
Number of 3.5" Bays	24
SAN Interface	iSCSI
Total Hard Drive Capacity Supported	72 TB
Number of Hard Drives Supported	24
Number of Hard Drives Installed	No
Height	7"
Width	19"
Depth	20.5"
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	50 lb
Number of Controllers	1
RAID Levels	0, 1, 3, 5, 6, 30, 50, 60, 0+1, JBOD
Controller Type	Serial Attached SCSI (SAS)Serial ATA/300
Limited Warranty	3 Year
